Specifications: Standards:
IEEE 802.3
IEEE 802.3u
IEEE 802.3x
IEEE 802.3ab
IEEE 802.3af
IEEE 802.3at
Device Interface:
1 x Gigabit PoE/PoE+ in port
1 x Gigabit PoE/PoE+ out port
1 x Power port (optional power adapter is not included)
LED indicators
Installation mounting points
Data Transfer Rate:
Ethernet: 10 Mbps (half duplex), 20 Mbps (full duplex)
Fast Ethernet: 100 Mbps (half duplex), 200 Mbps (full duplex)
Gigabit: 2000 Mbps (full duplex)
Power:
Powered by PoE/PoE+ Device
Consumption: 2 Watts (max.)
Features: 5 x Fast Ethernet ports
1Gbps switching capacity
Hardened IP50 rated aluminum switch
Extreme operating temperature range of -40° – 75° C (40° – 167° F)
Dual power inputs provide redundant power with overload current protection
Fanless design for silent operation
Includes DIN-Rail mount and wall mount brackets
Power supply sold separately (model: TI-M6024)
NDAA / TAA compliant
Lifetime
Features: 8 x Fast Ethernet ports
Hardened IP50 rated metal switch
Extreme operating temperature range of -40° – 75° C (-40° – 167° F)
Dual power inputs provide redundant power with overload current protection
Fanless design for silent operation
Alarm relay triggered by power failure
1.6Gbps switching capacity
Includes DIN-Rail mount and wall mount brackets
Power supply sold separately
Specifications: Standards
IEEE 802.3
IEEE 802.3u
IEEE 802.3x
IEEE 802.3ab
IEEE 802.3af
IEEE 802.3at
IEEE 802.3bt
Device Interface
1 x Gigabit PoE++ in port
1 x Gigabit PoE+ out port
1 x Gigabit 24/48V DC passive PoE out port
LED indicators
Wall mount
IP67 housing
Data Transfer Rate
Ethernet: 10Mbps (half duplex), 20Mbps (full duplex)
Fast Ethernet: 100Mbps (half duplex), 200Mbps (full duplex)
Gigabit: 2000Mbps (full duplex)
Performance
RAM buffer: 1Mb
MAC Address Table: 2K entries
Jumbo Frame: 9KB
DIP Switch
Adjust 24/48V DC passive voltage (default 48V DC)
Features: • 16 x Gigabit PoE+ ports
• 2 x Shared Gigabit ports (RJ-45 or SFP)
• 36Gbps switching capacity
• Internal power supply
• 440W PoE power budget
• Reduces equipment cost by delivering data and power over existing network cables
• Sturdy rack mountable metal housing
• Lifetime TRENDnet Manufacturer’s Warranty
Features: • 16 x Gigabit PoE+ ports
• 32Gbps switching capacity
• 246W PoE power budget
• Extend PoE+ signal up to 250m (820 ft.) at 10Mbps on ports 1 – 8
• DIP switch supports VLAN port isolation and storm control
• Smart Fans
• Reduces equipment cost by delivering data and power over existing network cables
• 1U 19” rack mountable metal housing with
