Specifications: Dimensions: 27.10 x 46.80 x 119.75 mm (1.07" x 1.84" x 4.71")
Weight: 150 g (5.29 oz)
Enclosure: Anodized Aluminum
Processor: APQ8053 with 2 GB RAM
eMMC Memory: 32 GB
Management Interface: UniFi App; UniFi Network Interface
Networking Interface: (1) 10/100/1000 Ethernet Port
Configuration Interface: BlueTooth LE with Ubiquiti Mobile Applications, Web browser
Buttons: (1) Power; (1) Reset
LEDs: (1) Power, White/Blue
Power Method: Standard 802.3 af PoE, DC 5V 1A Powered
Supported Voltage Range: Standard 802.3 af PoE, DC 5V 1A
Max. Power Consumption: 5W (PoE/Adapter)
Operating Temperature: 0 to 35° C (32 to 104° F)
Operating Humidity: 20 to 80% Noncondensing
Certifications: CE, FCC, IC
Features: Management interface:
Ethernet
Bluetooth
Networking interface: (1) GbE RJ45 port
Memory:
32 GB eMMC
3 GB RAM
SSD capacity: 1 TB 2.5" SATA SSD (user-upgradeable*)
*CloudKey+ only supports drives that can operate on 5V power. Drives that require additional power are not supported.
Power method:
PoE
Quick charge 2.0/3.0 power adapter, 9V DC, 2A
Max. power consumption 9.6W
Display 1.42" gray-scale OLED
LEDs: (1) Power: white/blue
Buttons:
(1) Power
(1) Factory reset
Ambient operating temperature: 0 to 35° C (32 to 104° F)
Ambient operating humidity: 20 to 80% noncondensing
Certifications: FCC, CE, IC
Capacity
HD cameras: 24
2K cameras: 14
4K cameras: 8
*Assumes the UCK-G2-PLUS is dedicated to UniFi Prot...
