Protocols: DHCP VLAN discovery; LLDP-MED for VLAN discovery; FTP/TFTP/HTTP/HTTPS server-based central provisioning; Hardware diagnostics; Manual or dynamic host configuration protocol (DHCP) network setup; Network address translation support for static configuration and Keep-Alive; QoS Support — IEEE 802.1p/Q tagging
(VLAN), Layer 3 TOS, and DHCP; Status and statistics reporting; Syslog Event Logging; Conforms to IEEE802.3-2005 (Clause 40) for physical media attachment; Conforms to IEEE802.3-2002 (Clause 28) for link partner auto-negotiation; Time and date synchronization using SNTP; RTCP and RTP support; IPv4; IPv6; Provisioning and call server redundancy support; DNS-SRV; UDP; SIP protocol support; IETF SIP (RFC 3261 and companion RFCs)
Security: 802.1X Authentication and EAPOL Media encryption via SRTP; Diges...
Standard: C-Tick, CISPR 22 Class B, EN 61000-3-2, NOM, EN 61000-3-3, EN55022 Class B, CB, ICES-003 Class
B, FCC Part 15 B, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, MIC, AS/NZS 3548,
EN 61000-4-5, EN 61000-4-11, EN 61000-4-8, UL 60950-1 Second Edition, KCC, ANATEL, cTUVus,
CSA C22.2 No. 60950-1 Second Edition, EN 60950-1 Second Edition, IEC 60950-1 Second Edition,
VCCI Class B, KN24, EN 55024: CISPR 24:2010
Specifications: Ports: 24 open mini-GBIC slots
Physical characteristics:
Dimensions: 10.3" x 8.1" x 1.8"
Weight: 2.0 lbs.
Environment:
Operating Temperature: 32°F to 104°F (0°C to 40°C)
Notes:
This product requires revision "B" or later mini-GBICs (product number ends with the letter "B", e.g. J4858B, J4859B).
When installed in a 5400 chassis, the J8706A module limits the operating temperature range of the chassis to 32°F to 104°F (0°C to 40°C).
Specifications: Ports:
4 CX4 10-GbE ports (IEEE 802.3ak Type 10Gbase-CX4)
Duplex: full only
Physical characteristics:
Dimensions: 10.3" x 8.1" x 1.8"
Weight: 1.7 lbs.
Environment: Operating Temperature: 32°F to 131°F (0°C to 55°C)
Cabling
Maximum distance:
15 m using CX4 cable
300 m using optical media converters and multimode fiber cable
Notes
Use CX4 10-GbE cable (0.5 m-15 m) or ProCurve 10-GbE CX4 Media Converter (J8439A)
No CX4 cables are included with this module.
Features: Product Type:Router
Ethernet Technology:Fast Ethernet
Number of Total Expansion Slots:1
Form Factor:Desktop
Rack-mountable
Compatible Rack Unit:1U
Total Number of Ports:5
Expansion Slot Type:Smart Interface Card
Product Name:A-MSR20-10 Multi Service Router
Flash Memory:32 MB
Standard Memory:256 MB
Primary Ports: 24 x RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Media Type: Auto-MDIX;
Duplex: 10BASE-T / 100BASE-TX: half or full; 1000BASE-T: full only; Ports 1-8 support MACsec
4 x SFP+ 10GbE ports
1 x port expansion module slot
Supports a maximum of 6 SFP+ ports or 2 1/10GBASE-T ports, with optional module
