Features: 5 x Fast Ethernet ports
1Gbps switching capacity
Hardened IP50 rated aluminum switch
Extreme operating temperature range of -40° – 75° C (40° – 167° F)
Dual power inputs provide redundant power with overload current protection
Fanless design for silent operation
Includes DIN-Rail mount and wall mount brackets
Power supply sold separately (model: TI-M6024)
NDAA / TAA compliant
Lifetime
Features: 4 x Gigabit PoE+ ports
1 x Gigabit port
2 x Gigabit SFP ports
Up to 120W PoE power budget
Hardened IP50 rated metal switch
Extreme operating temperature range of -40° – 75°C (-40° – 167°F)
Dual inputs provide redundant power with overload current protection
Alarm relay triggered by power failure
14Gbps switching capacity
Includes DIN-Rail mount and wall
Primary Port Speed: Total non-blocking throughput 70 Gbps
Switching capacity 140 Gbps
Forwarding rate 104.16 Mpps
LEDs: System Status
Ethernet PoE
Speed/ Link/Activity
SFP Speed/Link/Activity
Power: Power method Universal input, 100—240V AC, 50/60 Hz
Power supply AC/DC, internal, 500W
Supported voltage range 100—240V AC
Max. power consumption Excluding PoE output: 64W
Including PoE output: 500W
Total available PoE 500W
Features: • 4 x 2.5G PoE++ ports
• 1 x 10G RJ-45 port
• 1 x 10G SFP+ port
• 240W PoE power budget
• 60Gbps switching capacity
• Hardened IP50 rated metal switch
• Fast PoE minimizes wait time for powering up PoE devices
• Includes DIN-Rail and wall mounts
