Specifications: Dimensions: 3.80" x 1.20" x 0.90"
Output Interface:
3 x USB-A 3.0 Ports
1 x Gigabit Ethernet Port
Input Interface: 1 x USB-A 3.0 Connector
Chipset: RTL8153
Supported Systems: Windows (XP / Vista / 7 / 8 / 8.1 / 10), Mac OS X (10.5-10.11), Linux OS and Chrome OS
Package Contents:
USB 3.0 3-Port Hub & Gigabit Ethernet Adapter UE330
User Guide
Specifications: Hardware Version: 2
Interface:
"Data" Input Ports: 4 x RJ-45
"Data+Power" Output Ports: 4 x RJ-45
Data Rate: 10/100/1000 Mbps
LED:
System: Power x 1 (Green)
Per PoE Port: PoE ready / in-use x 4 (Green)
Network Cable:
10Base-T: 4-Pair UTP Cat. 5 up to 100m (328 ft.)
100Base-TX: 4-Pair UTP Cat. 5 up to 100m (328 ft.)
1000Base-T: 4-Pair UTP Cat. 5e, 6, up to 100m (328 ft.)
EIA/TIA- 568 100-ohm STP (100m, 328 ft.)
Power Requirements: DC 52V~56V
PoE Power Supply Type: Mid-Span
PoE Power Output: Per Port DC 52V 30.8 watts / 15.4 watts
Power Pin Assignment: 4/5(+), 7/8(-)
PoE Power Budget: 120 watts
Number of 802.3af PD Class 0, 1, 2, 3 can be powered: 4
Number of 802.3at PD Class 1, 2, 3 can be powered: 4
Number of 802.3at PD Class 0, 4 can be powered: 4
Standards Compliance:
IEEE 802.3 10Bas...
Specifications: Technical Information
Host Interface:
USB 3.0 Type A
Interfaces/Ports
Total Number of USB Ports:
3
Number of USB 3.0 Ports:
3
Number of Network (RJ-45) Ports:
1
Software
Operating System Supported:
Windows XP
Windows Vista
Windows 7
Windows 8
Windows 8.1
Windows 10
Windows 11
Windows Server 2003
Windows Server 2008 R2
Windows Server 2012
Windows Server 2012 R2
Windows Server 2016
Windows Server 2019
Windows Server 2022
Mac OS X 10.6 Snow Leopard
Mac OS X 10.8 Mountain Lion
Mac OS X 10.10 Yosemite
Mac OS X 10.11 El Capitan
Mac OS X 10.12 Sierra
Mac OS X 10.13 High Sierra
Mac OS X 10.14 Mojave
Mac OS X 10.15 Catalina
Mac OS X 11.0 Big Sur
Mac OS X 12.0 Monterey
Mac OS X 13.0 Ventura
ChromeOS
Linux 2.6.x
Physical Characteristic...
Specifications: Industry Standards:
IEEE 802.3af PoE, IEEE 802.3at PoE+
IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX, IEEE 802.3ab 1000BASE-T
Ports: 4
Maximum Cable Length: 328 ft [100 m]
Maximum Data Transfer Rate: 2 Gbps (Full-Duplex)
MTBF: 50,000 Hours
Power Output: 52V DC at 30.8W (PoE+)
Connector Type(s): 8 - RJ-45 Female
Enclosure Type: Steel
LED Indicators: 1-Power, 4-PoE In-Use
Center Tip Polarity: Positive
Input Current: 2-1 A
Input Voltage: 100 ~ 240 AC
Output Current: 2.31 A
Output Voltage: 52 DC
Plug Type: M
Power Consumption: 120 W Max
Power Source: AC Adapter Included
Included in Package:
1 - 4 Port Gigabit PoE+ Injector
1 - Universal Power Adapter
3 - Power Cords (NA/UK/EU)
1 - Instruction Manual
Specifications: Dimensions: 2.8 x 2.8 x 0.7 in. (71 x 71 x 16.6 mm)
Output Interface: 4 USB 3.0 Ports
Input Interface: USB 3.0 Type-A
Chipset: VIA VL812 Chipset with Latest Firmware
Supported Systems: Windows, Mac OS X and Linux systems
