Temperature: Operating Temperature: -4degreeF to 122degreeF/-20degreeC to 50degreeC
Storage Temperature: -40degreeF to 158degreeF/-40degreeC to 70degreeC
Frequency Band: Dual radio for simultaneous dual-band operation.
5 GHz 802.11ac 2x2 MIMO for up to 867 Mbps wireless data rate, with Multi User MIMO support (Wi-Fi 5).
2.4 GHz 802.11n 2x2 MIMO for up to 300 Mbps wireless data rate (Wi-Fi 4).
Standards: IEEE 802.11ac, 802.11n
Antenna: Integrated down-tilt omni-directional antennas with maximum individual antenna gain of 3.3dBi in 2.4GHz and 5.8dBi in 5GHz
LAN Ports: (1) uplink Gigabit Ethernet port, with POE-in support (802.3af)
Power Supply: IEEE 802.3af Ethernet switch
Cisco Power Injector - SB-PWR-INJ2-xx
AC adapter - SB-PWR-12V / 1.5A power adapter in a box
POE power
Peak power: 9.5Watts
Security: Captive Portal Authentication
Access Control
Wireless Mac Address Filtering
Wireless Isolation Between Clients
SSID to VLAN Mapping
Rogue AP Detection
802.1X Support
WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
WAN Ports: 1 RJ-45 autosensing 10/100/1000 PoE port (IEEE 802.3 Type 10BASE-T, IEEE
802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T, IEEE 802.3af PoE);
Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only
WAN Ports: 1 RJ-45 autosensing 10/100/1000 port (IEEE 802.3 Type 10BASE-T, IEEE 802.3u
Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex:
10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only
WAN Ports: 2 RJ-45 autosensing 10/100/1000 PoE+ ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T, IEEE 802.3at PoE+); Duplex:
10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only
Frequency Band: Dual Radio for simultaneous dual-band operation
5 GHz 802.11ac 3x3 MIMO for up to 1,300 Mbps wireless data rate, with Multi User MIMO support (Wi-Fi 5)
2.4 GHz 802.11n 2x2 MIMO for up to 300 Mbps wireless data rate (Wi-Fi 4)
Standards: IEEE 802.11ac, 802.11n
Antenna: Integrated downtilt omni-directional antennas with maximum individual antenna gain of 3.9dBi in 2.4GHz and 5.4dBi in 5GHz
LAN Ports: (1) uplink Gigabit Ethernet port, with POE-in support (802.3af)
Interface: 1 x PoE+ Gigabit LAN port (power input)
1 x Gigabit LAN port
Power port (optional non-PoE installation)
LED indicators
Mounting plate and cable guard
On/Off power button
Reset button
Standards: IEEE 802.3
IEEE 802.3u
IEEE 802.3x
IEEE 802.3ab
IEEE 802.3at
IEEE 802.1Q
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n (up to 400 Mbps @ 256 QAM)
IEEE 802.11ac Wave 2 (5 GHz 1: up to 867 Mbps, 5 GHz 2: up to 867 Mbps @ 256 QAM)
