Specifications: Maximum Resolution: 3840 x 2160
Host Interface: USB 3.0
DisplayPort: Yes
Number of DisplayPort Outputs: 1
System Requirements: Operating System(s):
Windows 8/8.1 (32/64bit)
Windows 7 (32/64bit)
Windows Vista (32/64)
Windows XP (32/64)
Windows 2000 (Aero 3D interface supported)
Specifications: Color: Gray
Humidity: 5% to 95% RH
Interface/Bridge: USB 2.0
Number of Ports: 2
Operating Temperature: 0°C to 55°C (32°F to 131°F)
Storage Temperature: -20°C to 85°C (-4°F to 185°F)
Max Baud Rate: 921.6Kbps
Data Bits: 7, 8
Stop Bits: 1 and 2
Parity: Odd, Even, Mark, Space, and None
Flow Control: Xon/Xoff, Hardware, and None
LED Indicators: 1 - Red - Power LED
Bus Type: USB 2.0
Connector Types: 1 - DB9 Male
Connector Types: 1 - Terminal Block
Connector Types: 1 - USB B Female
Power Adapter Included: Optional
Output Voltage: 5 DC
Output Current: 385mA
Center Tip Polarity: Positive
Plug Type: B
OS Compatibility:
Windows 98SE/ ME/ 2000/ XP(32/64bit)/ 2003(32/64bit)/ Vista(32/64bit)/ Server 2008(32/64bit)/ 7(32/64bit)/ Server 2008 R2, Mac 9.8/OS X, Linux 2.4.x and up;
Wind...
Specifications: Easy to Add Displays:
Extend video to a second monitor, duplicate the same video on both monitors or make the second monitor your primary display
Ideal for multitasking, viewing spreadsheet data, editing documents, giving presentations, watching movies and playing video games
Add up to 6 adapters for a total of 7 displays (Windows)
Add up to 4 adapters for a total of 5 displays (Mac)
No need to reboot system after adding or removing a monitor
Plug and play - no external power supply needed
Vibrant, Superior Video Quality:
Supports high-definition video resolutions up to 1920 x 1080 (1080p) @ 60 Hz
Features 128 MB DDR SDRAM of memory
Resumes automatically from hibernation and suspend modes
Broad Compatibility:
Works with 32- and 64-bit Windows 2000 and later
Works with 32- and 64-bit Intel Mac OS...
Specifications: Connector A: USB C (MALE)
Connector B: HDMI (FEMALE)
Chromebook Compatible: Yes
System Requirements
Windows XP, Vista, 7, 8 or 8.1 or Mac OS X 10.8.3 and later (32- and 64-bit versions)
Computer with USB-C port and at least 1.2 GHz single-core CPU and 512 MB of RAM
HDMI-enabled monitor
Supports Surface tablets running non-RT Windows 8 or 8.1
Package Contents: U444-06N-HD-AM USB 3.1 Gen 1 to HDMI Alternate Mode Dual/Multi-Monitor External Video Graphics Card Adapter
Quick Start Guide
Specifications: Audio: Yes
Chipset ID: MCT Trigger
Memory: 64MB DDRII SDRAM
Output Signal: HDMI
Ports: 2
Audio Specifications: 2-channel stereo
Maximum Digital Resolutions: 4K x 2K @ 30 Hz
Supported Resolutions
Output 1: 3840 x 2160, 2048 x 1152, 1920 x 1200, 1920 x 1080, 1680 x 1050, 1366 x 768, 1280 x 800, 1280 x 768, 1280 x 720, 1600 x 1200, 1400 x 1050, 1280 x 1024, 1024 x 768, 800 x 600, 640 x 480
Output 2: 2048 x 1152, 1920 x 1080, 1680 x 1050, 1366 x 768, 1280 x 800, 1280 x 768, 1280 x 720, 1600 x 1200, 1400 x 1050, 1280 x 1024, 1024 x 768, 800 x 600, 640 x 480
**All resolutions support 16 and 32 bit color
Wide Screen Supported: Yes
Connector A: 1 x USB Type-A (9 pin) USB 3.0 Male Input
Microsoft WHQL Certified: Yes
OS Compatibility: Windows 10 (32/64), Windows 8 / 8.1 (32/64), Windows 7 (32/64)
Note: T...
Specifications: Interface: USB 3.0
Support Devices: IDE & SATA I/II/III, SSDs, Hard Drives, CD/DVD/Blu-ray Drives
Drive Size: 2.5" & 3.5" & 5.25"
LED Indicators: 1 x IDE; 1 x SATA; 1 x USB; 1 x Power
System Requirements:
Microsoft Windows XP, Vista, 7, 8.1, 10 (32 or 64 bit)
Mac OS X v10.6 and Up
Linux OS
USB 3.0 or 2.0 Equipped System
For USB 3.0 Speeds, the System Must Support USB 3.0 Specification
Specifications: Bus Type: PCI Express Mounting Type: Full Profile PCI slot cover Chipset: VIA VL805 Interface: 2x USB 3.0 Port Type-A & Internal USB 20pin header Data Transfer Rate: USB 3.0 - 5 Gbit/s Connector Type (s) 1 - PCI Express x1 Male External Ports: 2x USB 3.0 Port Type-A Female Internal Ports 2 - USB 3.0 20pin male Power Supply: Build in Self-Powered Technology,Owns individual 2A power supply,no additional power input is required. Supports motherboard PCI-E X1 X4 X8 X16 slot Compatible OS: Compatible with 64-bit and 32-bit Windows 10 / 8.1 / 8/7 / XP.
Package Contents: 1 x PCIe USB 3.0 PCI express card,1 x Low Profile PCI Slot Cover
Specifications: Interface: USB 3.0
Support Devices: IDE & SATA I/II/III, SSDs, Hard Drives, CD/DVD/Blu-ray Drives
Drive Size: 2.5" & 3.5" & 5.25"
HDD Capacity: Up to 8TB
Power Supply: Ac Adapter
Material: Plastic
Dimensions: 63.00 x 42.00 x 14.00 mm
USB cable Length: 457.00 mm
System Requirements:
Microsoft Windows XP, Vista, 7, 8.1, 10 (32 or 64 bit)
Mac OS X v10.6 and Up
Linux OS
USB 3.0 or 2.0 Equipped System
For USB 3.0 Speeds, the System Must Support USB 3.0 Specification
Specifications: • Standard 2.5" IDE storage device form factor (100.2mm x 69.9mm x 9.8mm)
• LED indicators: Power On, Master and Slave Card Detect, and Disk Activity
• Can be a primary bootable device containing the OS and applications (depends on CF card specifications)
• Transparent to operating system and does not require any drivers
• Supports Microsoft Windows 2000, XP 32/64-bit, Server 2003 32/64-bit, Vista 32/64-bit, Server 2008 32/64-bit and Linux operating systems
• Power supply via IDE interface (44-pin SFF IDE connector, +5V)
IDE Interface
• 44-pin SFF (Small Form Factor) IDE connector
• Supports Ultra-DMA IDE Interface
• Does not support hot swap on the IDE interface
CF Interface
• 2 CF card slots (Master/Slave) supporting CF Type I form factor
• Supports PIO mode, DMA and Ultra-DMA mode with data transfer rate u...
Specifications: Host Interface: USB
Ports: 2 x 9-pin DB-9 Male RS-232 Serial
Operating Distance: EIA - RS232 Standard
Cable: USB cable
Platform Support: PC
PCB Layers: 4
Power Consumption: 100mA @ 3.3V
Operating Systems:
Microsoft Windows 7 32 bit & 64 bit Editions
Windows Vista 32 bit & 64 bit Editions
Windows XP 32 bit & 64 bit Editions
Form Factor: External
Dimensions: 3.94" x 4.13" x 1.02"
Weight (Approximate): 13.58 oz
Specifications: Serial Port
Ports: 2
Protocol: RS232
Connector: DB9 Connector - 9 Pin Male
Tx FIFO Size: 256
Rx FIFO Size: 32
Operating Distance: EIA - RS232 Standard
Cable: No Cable; Integrated Connector
Serial Port Settings
Max Baud Rate: 1,000,000 (1 MegaBaud)
Data Bits: 5, 6, 7 or 8
Parity: Odd, Even, None, Mark or Space
Stop Bits: 1 or 2
Flow Control: RTS / CTS, DSR / DTR, XON / XOFF
Tx / Rx Modes: Point to Point
Power
Power Input: Power Over Ethernet OR 5 - 30V DC input, reverse polarity protected
Power Over Ethernet: IEEE 802.3af
Power Supply 1 Description: Optional Global Power Supply - PW-800
General
Mounting Accessories 1 Description: DIN-Rail Mounting Kit - MK-048
PCB Layers: 4
Operating System Compatibility
Operating Systems:
Communicate with Device over TCP from any OS
Microsoft Windows 10
Microsoft Windows 8 32 bit & 64 bit Editi...
Changer Type: Type-C to MiniDP Adapter:
Chipset: Cypress CYPD1120
Signal input: USB 3.1 Type-C male
Signal output: Active MiniDP female
Support DP version: V1.2
DP port resolution support: Up to 4096 x 2160 (4K x 2K) (DisplayPort Alt mode)
MiniDP to HDMI Adapter:
Chipset: Chrontel CH7525
Signal input: MiniDP Male
Signal output: HDMI female (HDMI V1.4)
HDMI port Resolution support: Up to 4096 x 2160 (4K x 2K) at 30Hz
HDMI to VGA Adapter:
Chipset: Chrontel CH7101B
Signal input: HDMI male
Signal output: VGA female
VGA port Resolution support: Up to 1920 x 1200 at 60Hz
