Video Resolution: Max Supported Video Resolution: HDMI: 4096 x 2160 @ 60Hz
Console Connectors: Number of Ports: 16
PC/Server Connections: HDMI
Side A - Connector 1: HDMI (FEMALE)
Side A - Connector 2: (2) USB A (FEMALE)
Side A - Connector 3: 3.5MM (FEMALE)
Side B - Connector 1: (16) HDMI (FEMALE)
Side B - Connector 2: (16) USB B (FEMALE)
Side B - Connector 3: (16) 3.5MM (FEMALE)
Computer Keyboard and Mouse Interface: USB
Computer Monitor Interface: HDMI
LED Indicators: Orange x16 (Selected Port); Green x1 (Power); Green x16 (USB Link)
Console Connectors: Number of Ports: 8
PC/Server Connections: HDMI
Side A - Connector 1: HDMI (FEMALE)
Side A - Connector 2: (2) USB A (FEMALE)
Side A - Connector 3: 3.5MM (FEMALE)
Side B - Connector 1: (8) HDMI (FEMALE)
Side B - Connector 2: (8) USB B (FEMALE)
Side B - Connector 3: (8) 3.5MM (FEMALE)
Computer Keyboard and Mouse Interface: USB
Computer Monitor Interface: HDMI
LED Indicators: Orange x8 (Selected Port); Green x1 (Power); Green x8 (USB Link)
Temperature: Operating Temperature Range: 32 to 104 F (0 to 40 C)
Storage Temperature Range: -4 to 140 F (-20 to 60 C)
Type: Satellite Radio Antennas & Adapters,Satellite Radio Docks & Cradles,Satellite Radio Interfaces,Satellite Radio Tuners,Satellite Receivers,Sirius XM Radio Accessories
Package Contents: B126-1A0 HDMI Over Cat5 Active Extender Remote Unit
Screwdriver for adjustment of Equalization
Mounting hardware
External power supply (Input: 100-240V, 50/60Hz, 0.5A Output: 5V, 2A)
Owner's manual
Specifications: Connectors: 1 DB-25 Female, RS-485 / RS-422 Four Terminal Block, RJ11
Data Rate: Up to 100 Kbps under 4000ft.
Function Switches: SW1(DCE, DTE), SW2(TxON, RxON,TxRTS, RxON,TxDTR/RTS, RxDSR/ON)
Specifications: Max Distance: 150 m / 500 ft
Supported Resolutions:
1600x1200 @ 150ft(50m)
1280x1024 @ 300ft(100m)
1024x768 @ 500ft(150m)
The ST1218T 8 Port VGA Video Extender over Cat 5 is designed for use with our ST121 VGA over Cat 5 extension series, offering convenient VGA video distribution at distances of up to 492 feet (150 meters) using standard Cat 5 (or better) cabling.
Comprised of the transmitter unit only, the ST1218T requires one Receiver Unit (ST121R) per display that you are connecting.
For added versatility, the VGA over Cat 5 Repeater (ST121EXT) can be used to extend the distance between the transmitter and receiver by an additional 492-feet (150 meters), for a total distance of 984-feet (300 meters). Similarly, up to 3 repeater units can be used betwe...
Specifications: Input Voltage: 9 DC
Signal Type: XGA, VGA, SVGA, Multisync Monitor
Operating Environment: 5~40 deg C, 0~80% RH non-condensing
Certifications: FCC Part 15 Class A, CE Mark
Specifications: Audio: Yes
AV Input: HDMI
AV Output: HDMI
Cabling: Cat 6 UTP
Chipset ID: Norelsys NS 5730, NS5731
Audio Specifications: 7.1 Surround Sound
Max Distance: 140 m / 460 ft
Wide Screen Supported: Yes
Supported Resolutions:
3840x2160 (4K) 60Hz
2560x1600 60Hz
1920x1200 60Hz
1920x1080 (1080p) 60Hz
1280x720 (720p) 60Hz
*Lower resolutions and refresh rates, not stated but below the maximum, may also be supported
Center Tip Polarity: Positive
Input Voltage: 110V-240V AC
Output Current: 3 A
Output Voltage: 5V DC
Plug Type: M
Power Source: 2 AC Adapters Included
