Specifications: Easy to Add Displays:
Extend video to a second monitor, duplicate the same video on both monitors or make the second monitor your primary display
Ideal for multitasking, viewing spreadsheet data, editing documents, giving presentations, watching movies and playing video games
Add up to 6 adapters for a total of 7 displays (Windows)
Add up to 4 adapters for a total of 5 displays (Mac)
No need to reboot system after adding or removing a monitor
Plug and play - no external power supply needed
Vibrant, Superior Video Quality:
Supports high-definition video resolutions up to 1920 x 1080 (1080p) @ 60 Hz
Features 128 MB DDR SDRAM of memory
Resumes automatically from hibernation and suspend modes
Broad Compatibility:
Works with 32- and 64-bit Windows 2000 and later
Works with 32- and 64-bit Intel Mac OS...
Specifications: Maximum Analog Resolutions: 1920 x 1080
Maximum Digital Resolutions: 1920 x 1080
Supported Resolutions: 1920x1080 (1080p) @ 60Hz
Wide Screen Supported: Yes
Note: This adapter will not work with Samsung Chromebooks
Humidity: 40% to 85% RH Non-Condensing
Operating Temperature: 0 to 60 degree C
Storage Temperature: -10 to 70 degree C
Specifications: Audio: Yes
Chipset ID: STDP4320
Converter Type: MST Hub
Output Signal: HDMI
Ports: 2
Maximum Digital Resolutions: 3840x2160 @ 30 Hz
Supported Resolutions:
Note: MST shares 21.6 Gbps across all attached displays. Higher resolutions can restrict the available bandwidth with the remaining ports, please see our guideline below for determining an ideal resolution for your setup.
Average resolution bandwidth allocation
1920 x 1080 (High-definition 1080p) @60 Hz - 22%
1920 x 1200 @60hz - 30%
2560 x 1440 @60hz - 35%
2560 x 1600 @60hz - 38%
3840 x 2160 (Ultra HD 4K) @30 Hz - 38%
Note: Exceeding 100% will reduce functionality.
Wide Screen Supported: Yes
Connector A: 1 x USB-C (24 pin) DisplayPort Alt Mode Male Input
Specifications: Chipset ID: MCT - Trigger 1+
Memory: 16MB SDRAM
USB Pass-Through: No
General Specifications: This USB video adapter uses a Trigger family chipset. If you’re connecting this device to a computer along with additional USB video adapters or docking stations, please avoid using devices with a DisplayLink or Fresco family chipset.
Supported Resolutions: Standard (1600 x 1200, 1400 x 1050, 1280 x 1024, 1280 x 960, 1152 x 864, 1024 x 768, 800 x 600) / Widescreen (1680 x 1050, 1440 x 900, 1280 x 800, 1280 x 768, 1152 x 864, 800 x 600)
Connector A: 1 x USB Type-A (4 pin) USB 2.0 Male Input
OS Compatibility: Windows 10 (32/64) / Windows 8 / 8.1 (32/64) / Windows 7(32/64) / Windows Vista (32/64) / Windows XP (32/64)
System and Cable Requirements: One available USB 2.0 port
Part Number: Input: 1 x USB 3.0 Cable1 x HDMI1 x VGA2 x USB 3.01 x RJ45 Gigabit EthernetCombo: 1 x SD Card Reader,1 x Micro SD Card Reader
Type: USB to HDMI Adapters
Color: Black
Features: Upstream USB3.0 foldable extension cable designed for Mini Dock handy travelling
Built in HDMI port maximum resolution up to 2560x1600 and VGA port reach at 1080p
Two USB-A ports extended USB3.0 (5Gbps) data transferring, and USB2.0 compliance
Gigabit Ethernet with devices wake up function
Combo built in USB3.0 SD and TF / Micro SD
Specifications: Connector A: USB C (MALE)
Connector B: HD15 (FEMALE)
Chromebook Compatible: Yes
System Requirements
Windows XP, Vista, 7, 8 or 8.1 or Mac OS X 10.8.3 and later (32- and 64-bit versions)
Computer with USB-C port and at least 1.2 GHz single-core CPU and 512 MB of RAM
HDMI-enabled monitor
Supports Surface tablets running non-RT Windows 8 or 8.1
Specifications: Maximum Resolution: 3840 x 2160
Host Interface: USB 3.0
DisplayPort: Yes
Number of DisplayPort Outputs: 1
System Requirements: Operating System(s):
Windows 8/8.1 (32/64bit)
Windows 7 (32/64bit)
Windows Vista (32/64)
Windows XP (32/64)
Windows 2000 (Aero 3D interface supported)
