Features: - Two video stream groups for dual display, each group only supports one to use simultaneously.
- Compatible with TBT4/3 and other USB-C Alt Mode ports on Mac or Windows computer.
- Supports mirror and extend modes.
- Boasts excellent heat dissipation capabilities and occupies minimal space, making it convenient to carry around.
Package Contents: 1x USB 3.0 to DP/HDMI Dual Display Adapter(cable length: 90mm/3.5in), 1x CD-Shaped Card for Driver Download Links, 1x Quick Start Guide
Specifications: Audio: Yes
Chipset ID: T5-302/MCT
Output Signal: HDMI
USB Pass-Through: No
Audio Specifications: 2-Channel Stereo (48Khz)
General Specifications: This USB video adapter uses a Trigger family chipset. If you’re connecting this device to a computer along with additional USB video adapters or docking stations, please avoid using devices with a DisplayLink or Fresco family chipset
Maximum Digital Resolutions: 1920 x 1200 / 1080p
Supported Resolutions:
Widescreen(16/32 bit):
1920 x 1200, 1920 x 1080, 1680 x 1050, 1600 x 900, 1440 x 900, 1360 x 768, 1280 x 800, 1280 x 768, 1280 x 720
Standard(16/32 bit):
1600 x 1200, 1400 x 1050, 1280 x 1024, 1280 x 960, 1152 x 864, 1024 x 768, 800 x 600
Connector A: 1 - USB Type-A (9 pin) USB 3.0 Male Input
Connector B: 1 - HDMI (19 pin) Female Output
Humidi...
Specifications: Audio: Yes
Chipset ID: STDP4320
Converter Type: MST Hub
Output Signal: HDMI
Ports: 2
Maximum Digital Resolutions: 3840x2160 @ 30 Hz
Supported Resolutions:
Note: MST shares 21.6 Gbps across all attached displays. Higher resolutions can restrict the available bandwidth with the remaining ports, please see our guideline below for determining an ideal resolution for your setup.
Average resolution bandwidth allocation
1920 x 1080 (High-definition 1080p) @60 Hz - 22%
1920 x 1200 @60hz - 30%
2560 x 1440 @60hz - 35%
2560 x 1600 @60hz - 38%
3840 x 2160 (Ultra HD 4K) @30 Hz - 38%
Note: Exceeding 100% will reduce functionality.
Wide Screen Supported: Yes
Connector A: 1 x USB-C (24 pin) DisplayPort Alt Mode Male Input
