Specifications: Bus Type: USB 2.0
Chipset ID: FTDI - FT232RL
Interface : Serial
Port Style: External Hub
Ports: 16
Data Bits: 7, 8
FIFO: 256 Bytes
Max Baud Rate: 921.6 Kbps
Maximum Data Transfer Rate: 480 Mbps
Parity: Odd, Even, Mark, Space, None
Serial Protocol: RS-232
Stop Bits: 1, 2
LED Indicators 16 - Data Receive
16 - Data Transmit
Center Tip Polarity: Positive
Input Current: 1.5 A
Input Voltage: 100 ~ 240 AC
Output Current: 3 A
Output Voltage: 12 DC
Plug Type: N
Power Consumption: 36 W Max.
Power Source: AC Adapter Included
Humidity: 20~80% RH (Non-condensing)
Operating Temperature: -40°C to 85°C (-40°F to 185°F)
Storage Temperature: -65°C to 150°C (-85°F to 302°F)
Enclosure Type: Steel
Specifications: Bus Type: USB 2.0
Interface: Serial
Data Bits: 7, 8
FIFO: 256 Bytes
Max Baud Rate: 921.6 Kbps
Maximum Data Transfer Rate: 480 Mbps
Parity: Odd, Even, Mark, Space, None
Serial Protocol: RS-232
Stop Bits: 1, 2
LED Indicators: 8 x Data Transmit, 8 x Data Receive
Center Tip Polarity: Positive
Input Current: 1.5 A
Input Voltage: 100 ~ 240 AC
Output Current: 3 A
Output Voltage: 12 DC
Plug Type: B
Power Consumption: 36 W Max.
Humidity: 20 - 80% RH (Non-condensing)
Specifications: Ports: 8
Bus Type: USB 2.0
Port Style: External Hub
Chipset ID: FTDI FT2232H
Performance
Max Baud Rate: 921.6 Kbps
Maximum Data Transfer Rate: 921.6 Kbps
Serial Protocol: RS-232
Data Bits: 7, 8
FIFO: 4096 byte Transmit and Receive
Parity: Odd, Even, Mark, Space, None
Stop Bits: 1, 2
Type: 8-Port Industrial USB to RS-232/422/485 Serial Adapter
Color: Black
Changer Type: USB to RS-232/422/485 Serial
Specifications: Converts a single USB port into eight RS232/RS422/RS485 serial ports over USB 2.0 with four modes: RS232, RS422, 4-wire and 2-wire RS485
15 kV ESD protection (Level 4) against noise emissions and electrical voltage surges
DIN rail and wall mountable
Rugged IP30 rated metal hub housing and screw-locking host connection, ideal for harsh industrial environments
Data transfer baud rate up to 921.6Kbps
Single USB 2.0 hub port (pass-through) for daisy chaining, or for connecting an additional USB device to the host
COM port expansion with COM retention
Self-powered with included external power adapter
