Specifications: Function
Operating System Requirements
Windows Windows Vista, Windows 7, Windows 8, Windows 8.1
Mac Mac OS X10.3+
USB Specification USB 2.0
Cable Connections
Input Transmitter: USB Type B Female x 1; Receiver: RJ45 Ethernet Connector
Output Transmitter: RJ45 Ethernet connector; Receiver: USB Type A Female x 4
Transfer Rate Up to 480 Mbps
Cable Length Transmitter: USB cable 1ft (included); Receiver: Cat 5, Cat 5e or Cat 6 cable (not included) up to 164ft (50m)
Cable Distance Maximum cable distance from Transmitter to Receiver: 164ft (50m)
Cable Type Ethernet Cat 5, Cat 5e or Cat 6 required for connection between receiver and transmitter.
Connectors
AC Power Inlets Barrel type
Max Output Power 500mA @ 5V
Power Supply 2A @ 5VDC
LEDs
Power On
Operating Te...
Specifications: 1. HDMI resolution supports: 1080p@50/60Hz, 1080i@50/60Hz, 720p@50/60Hz, 576p@50Hz, 576i@50Hz, 480p@60Hz, 480i@60Hz
2. Audio format supports: DTS-HD/D o l b y-trueHD/DTS/D o l b y-AC3/ DSD.
4. Supports 3D(Note: To get 3D, all units connected to the extender must support 3D)
5. Transmission bandwidth: 1.65Gbps
6. HDMI cable length: AWG26 HDMI cable up to 8.0 meters(xx ft)
7. Power Supply: DC 5V/1A(2pcs)
Specifications: Video
Standards: HDMI 1.3; HDCP 1.2
Maximum pixel clock: 165MHz
Maximum data rate: 6.75Gbps
Resolution: 1920X1080P@60Hz
Connector: HDMI-A
Impedance: 100O
IR
Interface: 3.5mm seat
Signal direction: directional
Signal type: Digital
IR frequency: 20~60 KHz ;
UTP
Interface: RJ45/IEEE-568B
Transmission distance: CAT5e:50m/164ft,CAT6:60m/ 196ft
Other
Power supply: The power adapter: DC 5V/1A
Power dissipation: MAX 3W
Temperature: Operating: -5? ~ +70?
Humidity: Operating: 5% ~ 90%
Dimension: 94*71*25mm
The warranty: 1 year free warranty
Specifications: Platform: x86 Based, 32 bit PC's (Intel / AMD) and Macs w/ USB Support.
Interface Type: USB
Base Connectors: USB Type A Male; RJ45 Female
Remote Connectors: USB Type A Female; RJ45 Female
System Requirements: MS Windows 98SE/Me/2000/XP.
