Specifications: 03WDX, 1 gigabytes_per_second, Ethernet Splitter 1 to 4 with Lan Cable, 0.72 L x 0.82 W x 0.27 H inches, 100 grams, 1x Ethernet Splitter 1 to 4, 1 Year
Specifications: Interfaces
Relay
8 normally open relays (8 x 2-pole terminal block)
Contact Rating: Max 24 VDC, 2A
Ethernet
1 x RJ-45 Female, 10/100Base-T
Supported Protocol: ICMP, TCP/IP, DHCP, HTTPS, SSH
DHCP-enabled. The following default IP settings will be used if no IP is assigned within 30 seconds:
IP: 192.168.0.60
Subnet Mask: 255.255.255.0
Switches
Controller ID: 1 x 16-segment Switch
Expander ID: 1 x 8-segment Switch
Reset Button: 1 x Semi-recessed Pushbutton
USB: 1 x USB Type A (Firmware upgrade only)
Power
Consumption 5 VDC, 10 W (Adapter); 48 VDC, 13 W (PoE, PoE 802.3 AF/AT compatibility)
Output 12 VDC, 300 mA
Specifications: VE803T
Connectors
HDMI In: 1 x HDMI Type A Female (Black)
USB: 1 x USB Type B Female (White)
HDMI/USB Port: 2 x RJ-45 Female (Silver)
Power: 1 x DC Jack
Switches:
EDID Selection: 1 x slide switch
LEDs
Power: 1 (Green)
Video:
1080p @ 60Hz, at 40m
1080i @ 60Hz, at 60m
Power Consumption: DC5V, 1W
PhysicalProperties
Housing: Metal
VE803R
Connectors
HDMI Out: 1 x HDMI Type A Female (Black)
USB: 1 x USB Type A Female(White)
HDMI/USB Port: 2 x RJ-45 Female (Silver)
Power: 1 x DC Jack
Switches
EQ Compensation: 1 x 8 position switch
LEDs
Power: 1 (Green)
HDMI: 1 (Green)
USB: 1 (Green)
Video:
1080p @ 60Hz, at 40m
1080i @ 60Hz, at 60m
Power Consumption: DC5V, 3.9W
PhysicalProperties
Housing: Metal
Specifications: 03WDX, 1 gigabytes_per_second, Ethernet Splitter 1 to 4 with Lan Cable, 0.72 L x 0.82 W x 0.27 H inches, 100 grams, 1x Ethernet Splitter 1 to 4, 1 Year
Type: VGA Video + Audio with RS-232 Serial and IR Control over IP Transmitter
Max Extend Distance: 328 feet
Color: Black
Specifications: Extends and Distributes VGA Video + Audio, Serial and IR Control Signals over Cat5/6 Cabling
Converts source video to IP-based signal transmitted to and distributed through network switch
Extends signal up to 328 ft. (100 m) from switch
Can also connect directly to receiver up to 328 ft. away
Designed for Managed Network Switches with IGMP
Allows login and remote management via switch interface
Display single source on single display or distribute single signal to multiple displays
Video source can be sent to any analog or digital display, including HDMI and DisplayPort
Connect up to 64 transmitters and 255 receivers in single managed switch installation
HDMI output for connecting a local display
Enhance...
Specifications: NEW 60M HDMI Over Network Extender 1080P HDMI Transmitter by RJ45 CAT5e CAT6 LAN Extensor
Video
Standards----------HDMI 1.4; HDCP 1.4
Maximum pixel clock------165MHz
Maximum data rate-------10.2Gbps
Resolution ------1920X1080P@60Hz
Connector-----HDMI-A
Impedance--------100O
UTP
Interface-----RJ45/ IEEE-568B
distance--------CAT5e:50m/164ft,CAT6:60m/ 196ft
Other
Power supply-----The power adapter: DC 5V/1A
Power dissipation------MAX 3W
Temperature-------Operating: -5? ~ +70?
Humidity-------Operating: 5% ~ 90%
Dimension-------94*71*25mm
The warranty--------1 year free warranty
Specifications: Interfaces
Serial
4 x Programmable Bi-directional RS-232/422/485 Port
(4 x DB9 Male Connector, configurable via pin assignments);
Baud Rate: 300 to 115200 (default: 9600);
Data Bit: 8 (default) or 7;
Stop Bit: 1 (default) or 2;
Parity: None (default), Even or Odd;
Flow Control: None (default) RTS/CTS
Ethernet
1 x RJ-45 Female, 10/100Base-T
Supported Protocol: ICMP, TCP/IP, DHCP, HTTPS, SSH
DHCP-enabled. The following default IP settings will be used if no IP is assigned within 30 seconds:
IP: 192.168.0.60
Subnet Mask: 255.255.255.0
Switches
Controller ID: 1 x 16-segment Switch
Expander ID: 1 x 8-segment Switch
Reset Button: 1 x Semi-recessed Pushbutton
USB: 1 x USB Type A
Power: Consumption 5 VDC, 7.5 W(adapter) ; 48VDC, 9.5 W(PoE, PoE 802.3 AF/AT compatibility)
Specifications: Video
Standards: HDMI 1.3; HDCP 1.2
Maximum pixel clock: 165MHz
Maximum data rate: 6.75Gbps
Resolution: 1920X1080P@60Hz
Connector: HDMI-A
Impedance: 100O
IR
Interface: 3.5mm seat
Signal direction: directional
Signal type: Digital
IR frequency: 20~60 KHz ;
UTP
Interface: RJ45/IEEE-568B
Transmission distance: CAT5e:50m/164ft,CAT6:60m/ 196ft
Other
Power supply: The power adapter: DC 5V/1A
Power dissipation: MAX 3W
Temperature: Operating: -5? ~ +70?
Humidity: Operating: 5% ~ 90%
Dimension: 94*71*25mm
The warranty: 1 year free warranty
