Specifications: Audio: Yes
Chipset ID: MCT - T6-688L
Memory: DDR 4Gb
Output Signal: DisplayPort
Audio Specifications: 2-channel stereo
General Specifications:
This USB video adapter uses a Trigger family chipset. If you’re connecting this device to a computer along with additional USB video adapters or docking stations, please avoid using devices with a DisplayLink or Fresco family chipset.
Maximum Digital Resolutions: 4K x 2K @ 30Hz
Supported Resolutions Widescreen(16/32 bit):
3840×2160, 2048x1152, 1920x1200, 1920x1080, 1680x1050, 1366x768, 1280x800, 1280x768, 1280x720
Standard(16/32 bit):
1600x1200, 1400x1050, 1280x1024, 1024x768, 800x600, 640X480
Wide Screen Supported: Yes
Connector(s)
Connector A: 1 - USB Type-A (9 pin) USB 3.0 Male Input
Connector B: 1 - DisplayPor...
Specifications: Audio: Yes
Chipset ID: MCT Trigger
Memory: 64MB DDRII SDRAM
Output Signal: HDMI
Ports: 2
Audio Specifications: 2-channel stereo
Maximum Digital Resolutions: 4K x 2K @ 30 Hz
Supported Resolutions
Output 1: 3840 x 2160, 2048 x 1152, 1920 x 1200, 1920 x 1080, 1680 x 1050, 1366 x 768, 1280 x 800, 1280 x 768, 1280 x 720, 1600 x 1200, 1400 x 1050, 1280 x 1024, 1024 x 768, 800 x 600, 640 x 480
Output 2: 2048 x 1152, 1920 x 1080, 1680 x 1050, 1366 x 768, 1280 x 800, 1280 x 768, 1280 x 720, 1600 x 1200, 1400 x 1050, 1280 x 1024, 1024 x 768, 800 x 600, 640 x 480
**All resolutions support 16 and 32 bit color
Wide Screen Supported: Yes
Connector A: 1 x USB Type-A (9 pin) USB 3.0 Male Input
Microsoft WHQL Certified: Yes
OS Compatibility: Windows 10 (32/64), Windows 8 / 8.1 (32/64), Windows 7 (32/64)
Note: T...
Type: USB-C, HDMI or Mini DisplayPort to HDMI Converter Cable
Color: Black
Cable Length: 6.6 ft.
Specifications: Adapter Style: Cable Adapter
Audio: Yes
Converter Type: Passive
Connector A: 1 x Mini-DisplayPort (20 pin) Male, 1 x HDMI (19 pin) Male, 1 x USB-C (24 pin) Male
Connector Type(s): 1 x USB Micro-B (5 pin) Female
Power Source: USB-Powered
Humidity: 5 to 90% RH
Operating Temperature: 0 to 60 degree C (32 to 140 degreeF)
Storage Temperature: -10 to 80 degree C (14 to 176 degree F)
Specifications: Connector A: USB C (MALE)
Connector B: HDMI (FEMALE)
Chromebook Compatible: Yes
System Requirements
Windows XP, Vista, 7, 8 or 8.1 or Mac OS X 10.8.3 and later (32- and 64-bit versions)
Computer with USB-C port and at least 1.2 GHz single-core CPU and 512 MB of RAM
HDMI-enabled monitor
Supports Surface tablets running non-RT Windows 8 or 8.1
Package Contents: U444-06N-HD-AM USB 3.1 Gen 1 to HDMI Alternate Mode Dual/Multi-Monitor External Video Graphics Card Adapter
Quick Start Guide
Changer Type: Type-C to MiniDP Adapter:
Chipset: Cypress CYPD1120
Signal input: USB 3.1 Type-C male
Signal output: Active MiniDP female
Support DP version: V1.2
DP port resolution support: Up to 4096 x 2160 (4K x 2K) (DisplayPort Alt mode)
MiniDP to HDMI Adapter:
Chipset: Chrontel CH7525
Signal input: MiniDP Male
Signal output: HDMI female (HDMI V1.4)
HDMI port Resolution support: Up to 4096 x 2160 (4K x 2K) at 30Hz
HDMI to VGA Adapter:
Chipset: Chrontel CH7101B
Signal input: HDMI male
Signal output: VGA female
VGA port Resolution support: Up to 1920 x 1200 at 60Hz
Specifications: Audio Specifications: HDMI and mDP output - 7.1 surround sound
General Specifications: Only one video output is supported on the video adapter at a time. If multiple connections are made, only one of the outputs will function.
Maximum Analog Resolutions: 1920 x 1200
Maximum Digital Resolutions: 3840 x 2160
Supported Resolutions:
HDMI and mDP output: 3840 x 2160, 2560 x 1600, 1920 x 1200, 1920 x 1080, 1280 x 720
DVI and VGA output: 1920 x 1200, 1920 x 1080, 1280 x 720
Video Revision: DisplayPort 1.2
Wide Screen Supported
Humidity: 40%-50%RH
Operating Temperature: 0°C to 70°C (32°F to 158°F)
Storage Temperature: -10°C to 80°C (14°F to 176°F)
