Specifications: 1 - Connector A: USB-C (24 pin) USB Power Delivery only
1 - Connector B: USB-C (24 pin) USB Power Delivery only & 3.5 mm Audio
Operating Temperature: 0°C to 45°C (32°F to 113°F)
Storage Temperature: -10°C to 70°C (14°F to 158°F)
Humidity: 10%-85% RH
Specifications: 4K Support: Yes
Audio: Yes
Bus Type: USB-C
Chipset ID: VLI - VL812 (USB 3.0 Hub), VLI - VL100 (USB Power Delivery), PS - PS171 (DVI), Realtek - RTL8153 (LAN)
Displays Supported: 1
Fast-Charge Port(s): No
Industry Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab; USB 3.0 - Backward compatible with USB 2.0 and 1.1
Auto MDIX: Yes
Compatible Networks: 10/100/1000 Mbps
Full Duplex Support: Yes
Maximum Data Transfer Rate: 5 Gbps (USB 3.0); 2 Gbps (Ethernet; Full-Duplex)
Maximum Digital Resolutions: 1920 x 1200 - 60 Hz (DVI)
Maximum Power Delivery Support: 60W
Output Signal: DVI-D (DVI Digital)
Type and Rate: USB 3.0 - 5 Gbit/s
UASP Support: Yes
Connector Type(s): 1 x USB Type-C (24 pin) USB 3.0 Male
OS Compatibility: Windows 7, 8.1, 10 / Mac OS 10.11 to 10.12 / Chrome OS
Note:
Not all...
Type: USB-C, HDMI or Mini DisplayPort to HDMI Converter Cable
Color: Black
Cable Length: 6.6 ft.
Specifications: Adapter Style: Cable Adapter
Audio: Yes
Converter Type: Passive
Connector A: 1 x Mini-DisplayPort (20 pin) Male, 1 x HDMI (19 pin) Male, 1 x USB-C (24 pin) Male
Connector Type(s): 1 x USB Micro-B (5 pin) Female
Power Source: USB-Powered
Humidity: 5 to 90% RH
Operating Temperature: 0 to 60 degree C (32 to 140 degreeF)
Storage Temperature: -10 to 80 degree C (14 to 176 degree F)
Specifications: CE Approval: Yes
Connectors: Inputs on integrated cable (to server): VGA: HD15 M; USB: USB Type A M; Outputs (to laptop): Mini USB Type B F (USB 2.0), with detachable USB Mini Type B male to USB Type A male cable
Laptop Requirements: PC running Windows 2000, Windows XP, or Windows Vista or Mac OS X 10.5 (Leopard) or higher (Intel processor only); (1) available high-speed USB port (100-mA current); 20 Megabytes available disk space for install; 24-bit color display
Power: From the server or laptop USB interface with a maximum of 500 mA at 5 VDC
Resolutions (Maximum): 1920 x 1200 at 60 Hz or 1600 x 1200 at 75 Hz
RoHS: Yes
Server Requirements: (1) USB port (full speed) for keyboard/mouse (500-mA current); analog VGA graphics output (analog DVI can be used with adapter); OS supporting absolute U...
Specifications: USB 3.1 Type-C to Mini DisplayPort adapter for connecting a USB-C enabled smartphone, tablet or computer to an Mini DP-equipped monitor or display Compatible with HDMI-enabled TVs/Monitors/Projectors for both video and audio transfer This USB-C to Mini DP adapter Only Compatible with device with DisplayPort Alt Mode, Windows computers may need updated USB-C or Thunderbolt 3 drivers from the manufacturer. Video resolution up to 4K2K@ 60Hz and backward 4K2K@30Hz and 1080p@60Hz for compatibility with most displays, monitors and projectors, compatible with the following PC, Laptop: iMac 2017 / iMac Pro 2017 MacBook Pro 2017 & 2016 MacBook 2016 & 2015 New Chromebook Pixel Dell XPS 15 & 13 & 12 Yoga 920 Yoga 910, For Yoga 910 users, please ONLY plug the adapter into the White USB-C female port. Yoga 900(Yoga 4 Pro) HP Spectre x360 13 & 15...
Specifications: Specification
1.Model: WL-UG7702H-A
2.Ports: Front: 3*HDMI port(4K@60Hz), 1*HDMI port(DP Alt Mode converted to HDMI) (4K@144Hz)
3.Rear: USB-C port(PD IN 140W), USB-C connector(PD pass-through 130W Charging)
4.Unit Size: LxWxH: 11.4x7x1.5 cm/4.5x2.8x0.6 inch
5.USB-C Cable Length: 25.6 cm/10.4 inch
6.Unit Weight: 132g/4.7oz
7.Material: Aluminum Alloy
Features: - Comes with 4*HDMI ports; this display adapter supports 3*4K@60Hz+1*4K@144Hz display output.
- 1 x PD port supports PD pass-through, power in 140W (PD3.1), and charges the laptop at 130W max.
- 1 x USB 3.2 Gen2 (10G) port and a strong, powerful GPU ensure stable video transmission.
- Video display using the SiliconMotion chip solution supports laptops including Thunderbolt 4/3, USB 3.1/3.0, and legacy USB-A port laptops.
Part Number: 1 x HDMI1 x Microphone input Jack Port1 x Earphone Output Jack Port
Type: USB to HDMI Adapters
Color: Silver
Specifications: - Supports a quad display setup, with two capable of delivering 4K@30Hz resolution.
- 1 x USB-C/USB-A connector supports 5Gbps data transmission.
- Supports extend and mirror modes.
- Ideal choice for stocking business analysis, office work, and video clipping.
- Compact size to carry.
- This good-quality, super design, and user-friendly docking adapter can
Specifications: 6 inch USB-C to VGA, USB 3.0, USB-C Power Pass-Through Multiport Dock
The multiport dock from PI Manufacturing allows you to expand the ports and display connectivity options for your desktop, laptop, or other USB-C enabled device. The dock include a VGA port for outputting to a VGA display with support for resolutions up to 1920x1200 or 1080p, an USB 3.0 port for plugging in printers, external hard drives, thumb drives, and more, and a USB-C power delivery pass-through port for charging via your laptop's power adapter while the dock is in use.
Compact / Portable Size
The USB-C dock is perfect for on-the-go travel and comes with all the ports necessary for most applications.
Display Resolution
Support for resolutions up to 1920 x 12...
Changer Type: USB Type-C to Type-A, HDMI & Type-C Adapter
Color: White
Specifications: Connect A: USB 3.1 Type-C Male
Connect B: USB 3.0 Type-A Female / HDMI Female / Type-C Female
PC:
MacBook 2015 and newer/ MacBook Pro 2016 and newer/ iMac 2017 and newer/ iMac Pro 2017 and newer
MacBook Air 2018/ iPad Pro 2018 / New Mac Mini
Dell XSP 15/13
ASUS T303ua/ ZenBook 3
Lenovo YOGA900/910/920 / Lenovo Thinkpad X1 Carbon 5th
Chromebook Pixel 2
HP EliteBook Folio G1/ Spectre 13 X360
Huawei Matebook
And more...
Smartphones:
Huawei Mate 10
Samsung Galaxy S8/S8+/S9 / Samsung Galaxy Note8/9
Microsoft Lumia 950 / LG G5 / V20 / V30
And more...
Changer Type: USB Type-C to Type-A, VGA & Type-C Adapter
Color: White
Specifications: Connect A: USB 3.1 Type-C Male
Connect B: USB 3.0 Type-A Female / VGA (HD15) Female / Type-C Female
Compatible Devices for USB 3.1 Type-C with DP Alt Mode or Thunderbolt 3 (not a full list)
PC:
MacBook 2015 and newer/ MacBook Pro 2016 and newer/ iMac 2017 and newer/ iMac Pro 2017 and newer
MacBook Air 2018/ iPad Pro 2018 / New Mac Mini
Dell XSP 15/13
ASUS T303ua/ ZenBook 3
Lenovo YOGA900/910/920 / Lenovo Thinkpad X1 Carbon 5th
Chromebook Pixel 2
HP EliteBook Folio G1/ Spectre 13 X360
Huawei Matebook
And more...
Smartphones:
Huawei Mate 10
Samsung Galaxy S8/S8+/S9 / Samsung Galaxy Note8/9
Microsoft Lumia 950 / LG G5 / V20 / V30
And more...
