Changer Type: USB-C to HDMI / RJ45 / USB 3.0 / USB-C
Color: Black
Specifications: 4K Support: Yes
Bus Type: USB-C
Chipset ID: VIA/VLI - VL102, VIA/VLI - VL817, Parade Technologies - PS176, RealTek - RTL8153
Displays Supported: 1
Fast-Charge Port(s): Yes
Power Delivery: 100W
Power Source:USB-Powered
Industry Standards:
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
USB 3.0 - Backward compatible with USB 2.0 and 1.1
Auto MDIX: Yes
Full Duplex Support: Yes
Maximum Data Transfer Rate:
5 Gbps (USB 3.0)
2 Gbps (Ethernet; Full-Duplex)
Maximum Digital Resolutions:
4096 x 2160p @ 24Hz or 3840 x 2160p (HDMI) @ 30Hz
UltraWide - 3440 x 1440p @ 60 Hz or 2560x1080 at 60Hz
Lower resolutions are also supported. For example, if the max is 3840 x 2160p (4K), it also supports 2560 x 1600p and 2560 x 1440p.
Type and Rate: U...
Specifications: Specification
1.Model: WL-UG7702H-A
2.Ports: Front: 3*HDMI port(4K@60Hz), 1*HDMI port(DP Alt Mode converted to HDMI) (4K@144Hz)
3.Rear: USB-C port(PD IN 140W), USB-C connector(PD pass-through 130W Charging)
4.Unit Size: LxWxH: 11.4x7x1.5 cm/4.5x2.8x0.6 inch
5.USB-C Cable Length: 25.6 cm/10.4 inch
6.Unit Weight: 132g/4.7oz
7.Material: Aluminum Alloy
Features: - Comes with 4*HDMI ports; this display adapter supports 3*4K@60Hz+1*4K@144Hz display output.
- 1 x PD port supports PD pass-through, power in 140W (PD3.1), and charges the laptop at 130W max.
- 1 x USB 3.2 Gen2 (10G) port and a strong, powerful GPU ensure stable video transmission.
- Video display using the SiliconMotion chip solution supports laptops including Thunderbolt 4/3, USB 3.1/3.0, and legacy USB-A port laptops.
