Specifications: LED: Blue LED Power Indicator
Material: Plastic
Power Connector Required: 1x SATA
Fans Ports: 10
Fan Connector Supported: 3-pin / 4-pin (3-pin not supported for PWM Function)
PWM Signal Input: 4-pin PWM Connector
Weight: 90g
Color: Black
Dimensions (L x W x H): 81 x 44 x 18 mm (3.2" x 1.75" x .70")
Specifications: Dimensions: 2.91" x 0.59" x 2.52" (WxHxD)
Weight: 0.14 lbs.
Mounting: Magnet / Velcro
Control Method: NZXT CAM software
Connections:
Internal-USB Cable - x1
SATA Power Cable - x1
Fan Splitter Cables - 3x 1 to 3 split
Input Connector: 12V DC / 2.6A
Output Channel Voltage: 5V DC
Output Channels:
2 x RGB Lighting Channels
3 x Fan Channels
LED Color: RGB
LED Modes: Preset, Smart, Custom, Audio, Game
Included Accessories:
2 x Magnet
2 x 3M Velcro
Specifications: Color: Black
Connectors: PWM 4pin connector x 1 to motherboard
SATA power cable x 1 to PSU
PWM 4pin header x 8, compatible with 3pin cable*
Length
PWM cable 500mm, SATA power cable 300mm
Capacitor size
2200µF
Dimension
54mm (W) x 19mm (H) x 40mm (D)
Specifications: Material Plastic Shell
Signal input:
Standard addressable RGB 3Pin +5V, D, G*
Motherboard addressable RGB 4pin +5V, D, NP, G*
Signal output: SilverStone custom addressable RGB 3pin +5V, D, G** x 8
Power Input: SATA 15pin
Output limitation (each port): 5V 9A (4.5A+4.5A)***
Included Parts:
8 x Standard addressable RGB 3pin cable
1 x SATA power cable
1 x Input signal cable
Specifications: Lighting Node PRO
Power input: 4.5V to 5.5V
Unit dimension: 55mm x 31mm x 12mm
RGB LED channels: 2
Max. RGB LED strip per channel: 4
Mini USB cable: 375mm
SATA Power cable: 440mm
HD RGB LED hub cable 485mm
Individually Addressable RGB LED strip
Length: 410mm
RGB LED chip count: 10
Protective cover: IP65-rated transparent silicone
Adhesion type: 4 magnets per strip and full-strip tape
RGB extension cable: 345mm
Specifications: HDD Compatibility: 2.5" SATA HDD
Material : SECC
Interface: USB 3.0 , SATA III, SATA II, SATA I
SATA Compatibility: SATA III, SATA II, SATA I
Transfer Rate: USB 3.0: up to 5 Gbps
Power Source: 4-pin cable
Specifications: Unit Dimension: 15.50 x 69.00 x 133.00mm Power Input: Logic: 2.97V to 3.63V, 4.5V to 5.5V Fan: 11.4V to 12.6V RGB LED: 4.5V to 5.5V Cable: USB: 440mm SATA Power: 465mm Thermal sensor: 610mm Fan extension: 300mm RGB LED channels: Two 2-pin connector Max. RGB LED strip per channel: 4 Max. RGB fan per channel:6 through 1 RGB LED hub
