Package Contents: One 6in wire stripper pliers
One 3-piece soldering aid set
One heat sink
One magnifying glass (3 x 38mm)
One stainless steel tweezers
One 6-piece precision screwdriver set
One 4.5in stainless steel side cutter pliers
One 5in stainless steel long nose pliers
One Phillips 3.2 x 75mm screwdriver
One Phillips 5.0 x 75mm screwdriver
One Slotted 5.0 x 75 mm screwdriver
One Slotted 3.2 x 75 mm screwdriver
One parts box
One 8-piece mini-electronic combination wrench set (5, 5.5, 6, 7, 8, 9, 10, 11mm)
One PU carrying case (315 x 240 x 93mm)
One soldering stand
One solder core
One 3-prong holder
One utility knife
one desoldering pump
One soldering iron
Features: 1. Multi-Magnetic Hand Tools : 62 in 1 Precision Screwdriver Set with 1 PCS Anti Static Wrist Strap is Professional hand tools to repair most of laptops, phones, game consoles, and other electronics.
2. Variety of Specialty Bits : With different kind of Screwdriver bits, which made of chrome-vanadium steel are
Specifications: Pro3000 Analog Toner Specifications
User interface:
Slide switch selects Continuity or Tone Mode
Push button switch selects SOLID, ALT or OFF
Tone mode LED
Continuity/Polarity LED
Solid Frequency: 1000 Hz nominal
Alternating Frequency: 1000/1500 Hz nominal
Over Voltage Protection: 60 Vdc in Toner/Polarity Mode
Output Power in Tone Mode: 8 dbm into 600 ohms
Output Voltage Level in Continuity Mode: 8 Vdc with fresh battery
Battery: 9V alkaline
Temperature: Operating: -20° C to 60° C, Storage: -40° C to 70° C
Pro3000 Analog Probe specifications
User interface:
ON/OFF pushbutton
Volume dial
Replaceable tip
3.5 mm earphone jack
Battery: 9V alkaline
Temperature: Operating: -20° C to 60° C, Storage: -40° C to 70° C
Specifications: Electrical
Loop Limit
2.4 kOmaximum at 48 VDC (nominal 15 mA minimum loopcurrent)
DC Resistance (Talk Mode)
150 Otypical at 80 mA current
AC Impedance (Monitor Mode)
Low impedance (Ring position) 600 Oat 1 KHz typical
High impedance (HI Z position) 100 kOminimum at 1 KHz
Rotary Dial Output
10 pps .5 pps
Pulsing Rate 60 % ± 2 %
Percent Break 800 ms typical
Interdigit Interval Leakage During Break
> 50 kO
DTMF Output
±1 % maximum
Tone Frequency Error Level per Tone Pair
dBm maximum, - dBm minimum
High versus Low Tone Difference
4 dB maximum
Physical
Length
8.75 in (22.2 cm)
Width
2.375 in (6.03 cm)
Height
3.375 in (8.57 cm)
Weight
10.8 oz (.307 kg) maximum
Environmental
Temperature
Operating: -5 °C to °C
Storage: -40 °C to °C
Drop
1 meter, 4 times
Altitude
To 3,000 meters (10,000 feet) maximum
Relative Humidity
10 %to 80 % (non...
Specifications: Test Pin Configuration:
- RJ45 EIA, TIA-568A/568B, and crossover cables
- RJ9, RJ11, RJ12, RJ14, RJ25, RJ45, and RJ61
- USOC 2, 4, 6, and 8
- Coax Video-BNC and CATV-F
- USB 3.0, USB 2.0
Transmitter Unit Interface:
- 1 x RJ port
- 1 x USB 3.0/2.0 Type-A port
- 1 x USB 3.0/2.0 Type-B port
- Test button
- Mode button
- On/off button
- LED indicators
- Battery compartment
- Receiver unit attachment port
Power Source
- Transmitter: 9 V DC battery (not included)
- Remote unit: No power needed
