Video: Reference Output x 6
Analog Black Burst or Tri-Level Sync, on BNC connectors
Power Supply: 12VDC on an AC Power Adapter
Specification: Television System:
625/25 PAL
525/29.97 NTSC
1080PsF23.98
1080PsF24
1080i50
1080i59.94
720p50
720p59.94
Selectable
Control: Dip Switch Format Selection
Feature: The Blackmagic Design CONVMSYNC is a sync generator. This generator will generate a reference signal in either high definition or standard definition parmeters. It is part of the Mini Converter series and offers six BNC outputs.
Space Saving
Broadcast Converter models are extremely compact, so you can install in the front or rear side of equipment racks, saving valuable equipment space.
Security
This device features a handy cable tie point to lock the power down tight and prevent your power being disconnected.
Formats...
Color: Color Space: REC 601, REC 709
Color Precision: 10-bit
SDI: SDI Input: Switchable (auto-selects) between SD, HD and 3 Gb/s SDI. Reclocked loop-through output
SDI Compliance: SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, and SMPTE 425M
Specification: Multi-Rate Support Auto detection of 2K, HD or standard definition inputs
Monitor Type: TFT active-matrix LCD
Screen Size: 2x 8" diagonal
Resolution; 800 x 480
Display Colors:...
Power Supply: 12 V power supply included with international socket adapters for all countries
Specification: Contact Closure: 25 pin D-type connector providing 8 up to isolated inputs and 8 relay contact closure outputs
Inputs: Optical isolators triggered by connection to ground (maximum 5 V @ 14 mA)
Outputs: Mechanical relay contact closure to ground (maximum 30 V @ 1 A)
Ethernet: 10 / 100 BaseT with loop through for connecting to other Ethernet enabled equipment
Computer Interface: 1 x USB 2.0 high speed interface for configuration and firmware updates
Software Included: Configured via ATEM Switcher utility
Firmware Upgrade: Firmware built into software driver. Loaded at system startup or via updater software
Operating System: Microsoft Windows 7 and Apple Mac OS X
Feature: Displays Tallies for Video Signals
Indicates On-air ...
Feature: The Blackmagic Design Universal Videohub 450W Power Card allows you to add up to three external 12V power supply bricks (not included) to the Univeral Videohub router frame, as needed. Three 12V/150W power supplies offer enough power for 72 x 72 BNC SDI or optical fiber routing.
Feature: The Blackmagic Design PSUPPLY-INT12V10W is a replacement power supply that can be used with any Mini Converter in the series. As with the original unit, this power supply includes socket adapters for international countries and also features a cable tie to prevent the wire from becoming accidentally disconnected.
Feature: The Teranex Mini Smart Panel, from Blackmagic Design, is designed to simply replace the existing front panel on any Teranex Mini Converter and instead provide a color LCD, spin dial, and six control buttons, including a menu control. You'll be able to adjust settings, browse menus, monitor conversions in progress, monitor audio levels, verify timecode, and verify the video standard being converted. The Smart Panel easily attaches in place of the standard front panel once the standard panel is taken off.
