Power Supply: Input: 100-240V, 50/60Hz, 1.5A
Output: 12.6V, 3A
Specification: Cable Type: VGA
Display Style: Splitter
Color: Black
Connector A: HD15 (FEMALE)
Connector B: RJ45 (FEMALE) x 4
Feature: Splits a single VGA signal into 5 (1 local, 4 remote)
Increase the number of displays to up to 25 (1 local, 24 remote) by daisychaining up to six B132-004-2 units together
A B132-100-1 or B132-100-WP-1 remote receiver unit is required for each connected monitor
Extends a 1920 x 1440 (60Hz) signal up to 500 ft., or a 1024 x 768 (60Hz) signal up to 1,000 ft., when using 24Awg, Solid Wire Cat5e/6 cable, such as Tripp Lite's N022-01K-GY (Cat5) and N222-01K-GY (Cat6)
EDID copy feature ensures optimal display compatibility
The range and number of monitors can be further expanded by adding B132-110 repeater units
Connect up to 4 remote unit...
Specification: Maximum Pixel Clock: 2x 165 MHz
Video Input Connector: (1) DVI-I 29-pin, female
Video Output Connector: (1) DVI-I 29-pin, female
Operating temperature range: +5 to +45 deg. Celsius
Power Supply: 5V DC (needed for programming only)
Power Consumption: 5 Watts (max)
Feature: Quick and easy way to store EDID information from any DVI display
Provides a virtual EDID to maintain active monitor status when switching away from a source
Supports resolutions up to 1920x1200, 2K, and 3840x2400 (Dual Link)
EDID write protection switch
No power is required after initial programming
