Specifications: Max Weight per mount (lbs): 19.8
Mounting Hole Pattern (mm): 75 x 75; 100 x 100
Screen rotation (portrait/landscape): 360°
Tilt/pan adjustment: Ball joint mechanism allows 40 degrees display adjustment in any direction from the vertical plane
Display pan adjustment: 90 degrees left and right, total of 180 degrees
Cable management: Integrated
Mounting options: Wall
Maximum reach (inches): 24
Maximum distance from the wall (inches): 24
Number of studs required: 1
Hardware required for installation: All mounting hardware included
Color: Black
Specifications: Device Support: Flat Panel Display
Load Capacity: 6-18 lb Maximum for Display
5 lb Maximum for Keyboard, mouse and barcode scanner
Maximum Screen Size Support: 24"
Rotation: 30° - Tilt
Pan: 360°
Rotation: 90°
Mounting Standards: VESA FDMI, MIS-D, 75/100, C (hole patterns = 100 x 100 mm and 75 x 75 mm)
Integrated mouse and barcode scanner holder provide easy access
Integrated fold-down keyboard tray with right/left mouse tray (includes built-in mouse pad surface)
Negative-tilt keyboard tray adjustable 0 to -10 degrees
Durable, easy-to-clean exterior composed of aluminum, high-grade plastic and powder-coated painted steel
Mounting Options: Mounts to sturdy vertical surfaces. Where applicable, attach to wood stud. Separately ordered Wall Track or Wall Plate accessory is recommended to strengthen...
Specifications: Color: Black
Construction Material: Steel
# of Displays Supported: 2
Articulating: Yes
Mounting Options: Desk & Grommet Clamp
Mounting Surface Thickness: Desk Clamp: Table Thickness 0.39 - 3.46 in. (10 - 88 mm)
Grommet Clamp: Table Thickness 0.39 - 2.95 in. (10 - 75 mm)
Grommet Mount Hole Size: 0.39 - 2.95 in. (10 - 75 mm)
VESA Hole Pattern(s): 75x75 mm / 100x100 mm
Wallmountable: No
Display Rotation: 360°
Display Swivel: +90° / - 90°
Display Tilt: + 45° / - 45°
Height Adjustment: Yes
Maximum Arm Span: 15.7 in [399 mm]
Maximum Display Size: 32in
Swivel / Pivot:
+/- 90° around the support post
+/- 180° at the shoulder
+/- 90° at the elbow
Weight Capacity (Per Display): 17.7 lb [8 kg]
Included in Package:
2 x VESA Mounts
1 x Swivel Arm Assembly
1 x Desk Clamp Assembly
1 x Pole
1 x Pole Cap
2 x Cable Mana...
Specifications: Color: Black
Construction Material: Aluminum
# of Displays Supported: 2
Articulating: Yes
Mounting Options: Desk Clamp
Mounting Surface Thickness: Desk Clamp: Table Thickness 0.39 - 3.46 in. (10 - 88 mm)
VESA Hole Pattern(s): 75x75 mm / 100x100 mm
Wallmountable: No
Display Rotation: 360°
Display Swivel: +90° / - 90°
Display Tilt: + 30° / - 30°
Height Adjustment: Yes
Maximum Arm Extension: 15.2 in [386 mm]
Maximum Display Size: 32in
Swivel / Pivot: +/- 90° around the support post
+/- 180° at the shoulder
+/- 90° at the elbow
Weight Capacity (Per Display): 17.7 lb [8 kg]
Included in Package:
1 x Desk Clamp Assembly, Lower
1 x Desk Clamp Assembly, Upper
1 x Swivel Arm Assembly
1 x Pole
2 x Desk Clamp Screws
3 x Pole Assembly Screws
1 x 4mm Hex Key
1 x 6mm Hex Key
8 x M4 x 12 mm Screws
8 x M5 x 12 mm Screws...
Specifications: Color: Black
Material: Steel/Aluminum alloy/Plastic
Max. wall mount hole pitch: 100 x 100 mm/ 75 x 75 mm (MIS-D 100 / MIS-D 75)
Screw Type: M4
Swivel: +/-90 degree
Tilt: +90 / -20 degree
Rotate(Pivot): 360 degree
Support max. weight: 2 ~ 10Kg (4.4~22.1lbs) per arm
Support flat panel size: <=24"
Min. Distance To The Wall: 97mm
Support desktop thickness: 8mm (0.32")~ 50mm (1.96")
Extended Arm Provided: 2
Net Weight: 3.8Kg (8.37Ibs)
Dimension: 500mm (W) x 497mm (H) x 619mm (D)
Specifications: Supports two displays between 15.00" - 24.00" with maximum weight 26.00 lbs. per display
Flexibility to tilt up and down +/- 20 degree
Swivel displays side to side +/- 20 degree
Rotate 90 degree for landscape or portrait mode
Hole pitch 100 mm x 100 mm VESA and 75.00 mm x 75.00 mm VESA
Specifications: Max Weight per mount (lbs): 26.5
Quick release Mounting Head: Yes
Mounting Hole Pattern (mm):
- 75 x 75; 100 x 100
- Require 200 x 100 Add AC-AP-2010 adaptor plate to your order
Screen rotation (portrait/landscape): 360°
Rotation around pole: 360° OR FIXED
Tilt/pan adjustment: Ball joint mechanism allows 20 degrees display adjustment in any direction from the vertical plane
Display pan adjustment: 90 degrees left and right, total of 180 degrees
Pole height (inches): 29.5
Cable management: Integrated
Mounting options: Desk clamp and bolt through
Pole diameter(inches): 1.6
Display Compatibility:
- Spacedec Donut Pole is compatible with most Flat Panel Displays between 12" (30cm) and 24" (61cm) that feature either 75mm x 75mm (3 x 3") or 100mm x 100mm (4 x 4") VESA mounting hole patterns
Mount...
Specifications: LCD Compatibility: < 27" or =27"
Product Includes: Vesa plate, aluminum articulating arm, desk clamp base
Full extension range of 23.4"
Capacity: 7-22 lbs. per monitor
Tilt: UP 90 degree, Down 45 degree
Pan: 180 degree
Rotation: 360 degree
Specifications: Max Weight per mount (lbs): 55
Quick release Mounting Head: Yes
Mounting Hole Pattern (mm): 75 x 75; 100 x 100
Screen rotation (portrait/landscape): 360°
Tilt/pan adjustment: Ball joint mechanism allows 20 degrees display adjustment in any direction from the vertical plane
Display pan adjustment: 90 degrees left and right, total of 180 degrees
Mounting options: Wall
Fixed Distance from wall to rear of display: 3.1"
Number of studs required: 1
Color: Black
