Specifications: # of displays supported: 2
Mounting Options: Desk Clamp
One-touch height adjustment: Yes
VESA Hole Pattern(s):
75x75 mm
100x100 mm
Display Rotation: 360°
Height Adjustment: Yes
Maximum Arm Extension: 22.3 in [567.5 mm]
Maximum Arm Span: 44.7 in [1135 mm]
Maximum Display Size: 30in
Mounting Surface Thickness: 90 mm (3.54 in.)
Pan: 180°
Swivel / Pivot:
135° around the support post
360° at the elbow
Tilt: +90° / -65°
Weight Capacity: 17.7 lb [8 kg]
Specifications: Max Weight per mount (lbs): 19.8
Mounting Hole Pattern (mm): 75 x 75; 100 x 100
Screen rotation (portrait/landscape): 360°
Tilt/pan adjustment: Ball joint mechanism allows 40 degrees display adjustment in any direction from the vertical plane
Display pan adjustment: 90 degrees left and right, total of 180 degrees
Cable management: Integrated
Mounting options: Wall
Maximum reach (inches): 24
Maximum distance from the wall (inches): 24
Number of studs required: 1
Hardware required for installation: All mounting hardware included
Color: Black
