Asrock Rack Server Riser Card/Accessories PAUL Low-profile PCIe IPMI Card

Be the first to review this product...
  • Low-profile PCIe IPMI card. add-in-card
  • ASPEED AST2500
  • PCI Express2.0 x1
  • 1 x RJ45 via Realtek RTL8211E for dedicated IPMI LAN (10/100/1000 Mbps) +1 x DB-15 (VGA)
  • Power consumption: 7.54W
This item is covered under the Manufacturer Only Return Policy.
+
+
Specs
Reviews
See all Q & A
avatar

Any questions? Our AI beta will help you find out quickly.

Try me now

Learn more about the ASRock Rack PAUL

Model
Brand ASRock Rack
Model PAUL
Details
Type Interface Module
Specifications Controller: ASPEED AST2500
Feature: Base Board Management Controller (IPMI2.0 with iKVM support)
VGA (1920x1200@60Hz 32bpp)
Memory: 2 SPI flash ROM 32MB
1 DDR4 SDRAM 4Gb

Physical Status
Form Factor: Low profile PCIe add-in-card
Dimensions: 168.45 x 68.9 mm

I/O
Upstream interface: PCI Express2.0 x1
External: 1 RJ45 via Realtek RTL8211E for dedicated IPMI LAN (10/100/1000 Mbps), 1 DB-15 (VGA)
Internal connectors: 2 SMBus header
1 x PMBus header
1 x IPMB header
1 x BMC reset
1 x BMC debug header
1 x V BIOS or system BIOS ROM
2 x BMC ROM
1 x Dual ROM select header
1 x TPM (13-pin, LPC)
1 x LPC header (13-pin)
2 x Fan header
1 x USB2.0 (5-pin): KVM and standby power
1 x header (18-pin): GPIO, NCSI
1 x header (18-pin): case open, system fail, GPIO, SMBus, PECI, voltage monitoring
1 x COM port (9-pin)
1 x micro-SD connector
1 x USB Type-A (USB 2.0)

Power
Power consumption: 7.54W
Input: 1 USB2.0 header (5-pin, 5VSB) Goldfinger (+12V)

Environment
Temperature: Operation temperature: 10°C ~ 35°C / Non operation temperature: -40°C ~ 70°C
Additional Information
First Listed on Newegg May 07, 2021

Warranty & Returns

Warranty, Returns, And Additional Information

Warranty

  • Limited Warranty period (parts): 1 year
  • Limited Warranty period (labor): 1 year
