Specifications: Serial Port
Ports: 1
Protocol: RS232
Connector: DB9 Connector - 9 Pin Male
Tx FIFO Size: 256
Rx FIFO Size: 32
Operating Distance: EIA - RS232 Standard
Cable: No Cable; Integrated Connector
Serial Port Settings
Max Baud Rate: 1,000,000 (1 MegaBaud)
Data Bits: 5, 6, 7 or 8
Parity: Odd, Even, None, Mark or Space
Stop Bits: 1 or 2
Flow Control: RTS / CTS, DSR / DTR, XON / XOFF
Tx / Rx Modes: Point to Point
Power
Power Input: Power Over Ethernet OR 5 - 30V DC input, reverse polarity protected
Power Over Ethernet: IEEE 802.3af
Power Supply 1 Description: Optional Global Power Supply - PW-800
General
Mounting Accessories 1 Description: DIN-Rail Mounting Kit - MK-048
PCB Layers: 4
Operating System Compatibility
Operating Systems:
Communicate with Device over TCP from any OS
Microsoft Windows 10
Microsoft Windows 8 32 bit & 64 bit Editi...
Operating Systems Supported: Windows CE 5.0, 98SE, 2000, XP, Vista, 7, 8, 8.1, 10
Windows Server 2003, 2008 R2, 2012, 2016, 2019
Linux 2.4.x to 4.11.x LTS Versions only
Network Interface: USER INTERFACE:
Indicator LEDs: Outputs, inputs, communication link and power
Controls: EDID setup button, 12 setup DIP switches
1 RS-232: On a Mini–USB female connector for firmware upgrade
S-Video: VIDEO:
Max. Data Rate: 10.2Gbps (3.4Gbps per graphic channel)
Max. Resolution: Up to 4K@60Hz (4:2:0) 24bpp
Standards Compliance: Supports HDCP 1.4 and HDBaseT 1.0
HDMI Support: Deep Color, x.v.Color™, Lip Sync, 7.1 PCM, Dolby TrueHD, DTS–HD, 2K, 4K, and 3D as specified in HDMI 2.0
Specifications: Bus Type: USB 2.0
Chipset ID: FTDI - FT232RL
Interface : Serial
Port Style: External Hub
Ports: 16
Data Bits: 7, 8
FIFO: 256 Bytes
Max Baud Rate: 921.6 Kbps
Maximum Data Transfer Rate: 480 Mbps
Parity: Odd, Even, Mark, Space, None
Serial Protocol: RS-232
Stop Bits: 1, 2
LED Indicators 16 - Data Receive
16 - Data Transmit
Center Tip Polarity: Positive
Input Current: 1.5 A
Input Voltage: 100 ~ 240 AC
Output Current: 3 A
Output Voltage: 12 DC
Plug Type: N
Power Consumption: 36 W Max.
Power Source: AC Adapter Included
Humidity: 20~80% RH (Non-condensing)
Operating Temperature: -40°C to 85°C (-40°F to 185°F)
Storage Temperature: -65°C to 150°C (-85°F to 302°F)
Enclosure Type: Steel
Specifications: 1 x RS-232 serial port (DB-9)
Captive (attached) 2-meter USB cable
Data Transfer Rate: Up to 230 Kbps
USB 1.0 and 1.1 compatible; backward compatibility for USB 2.0
Drivers for Windows 9x, Windows NT 4.0, Windows NT Embedded, Windows XP, Windows 2000, Windows CE, Windows Server 2003; Linux; Sun Solaris
