Specifications: Standards
IEEE 802.3
IEEE 802.3u
IEEE 802.3x
IEEE 802.3ab
IEEE 802.3af
IEEE 802.3at
IEEE 802.3bt
Device Interface
1 x Gigabit PoE++ in port
1 x Gigabit PoE+ out port
1 x Gigabit 24/48V DC passive PoE out port
LED indicators
Wall mount
IP67 housing
Data Transfer Rate
Ethernet: 10Mbps (half duplex), 20Mbps (full duplex)
Fast Ethernet: 100Mbps (half duplex), 200Mbps (full duplex)
Gigabit: 2000Mbps (full duplex)
Performance
RAM buffer: 1Mb
MAC Address Table: 2K entries
Jumbo Frame: 9KB
DIP Switch
Adjust 24/48V DC passive voltage (default 48V DC)
Features: • Wall mount
• IP66 weather rated
• Use with TRENDnet's industrial switches, fiber converters, and PoE injectors
• Rugged steel construction
• Hinged door with waterproof door lock
• Removable bottom plate
• Mounting hardware included
• Lifetime Warranty
Specifications: Standards:
IEEE 802.3
IEEE 802.3u
IEEE 802.3x
IEEE 802.3ab
IEEE 802.3af
Device Interface:
1 x Gigabit data/power in port
1 x Gigabit data out port
1 x Power out port
LED indicators
Adjustable output power DIP switch (5 V, 7.5 V, 9 V, 12 V)
Data Transfer Rate:
Ethernet: 10 Mbps (half duplex), 20 Mbps (full duplex)
Fast Ethernet: 100 Mbps (half duplex), 200 Mbps (full duplex)
Gigabit: 2000 Mbps (full duplex)
Jumper Cable:
2.0 to 2.0 mm
2.0 to 2.5 mm
Power:
PoE network cable input: 48 V DC, 0.38 A
Output: 5 V (2 A), 7.5 V (2 A), 9 V (1.7 A), 12 V (1.2 A)
Consumption: 0.3 Watts (max.)
