Ports Spec: 1 x Monitor/Video Port (15 pin D-Sub)
1 x 10/100 Base-T Ethernet (RJ-45) Jack
1 x Serial Port
1 x Stereo Audio-Out Jack (3.5 mm for speakers or headphone)
1 x Mono Audio-In Jack (3.5mm for microphone)
4 x Hi-Speed USB 2.0 Ports (two Power Ports and two standard USB ports both are backward compatible with USB 1.1 devices and support transfers up to 480Mbps)
Ports Spec: 5 x 4-pin Type A USB 2.0 USB
1 x RJ-45 Network
1 x 15-pin HD-15 VGA
1 x 24-pin DVI-D Digital Video
1 x 20-pin Display Port Digital Video
1 x eSATA
Audio
Ports Spec: One standard 15-pin VGA monitor output - Supports video resolutions up to 1280 x 1024 in 16-bit color. Just plug your external monitor's existing video cable into the port replicator.
Two standard USB 2.0 ports - Ideal for most USB devices, including printers, keyboards, mice, and memory keys. These USB 2.0 ports are backward-compatible with USB 1.1 devices.
Two powered USB 2.0 ports - Deliver 2x the power of standard USB ports (1000 mA). The included external AC power adapter allows these ports to stay active even when the notebook is shut down or disconnected . It is ideal for USB devices that draw power from the notebook, including external optical drives and hard drives, or for USB devices that require recharging. These USB 2.0 ports are backward-compatible with USB 1.1 devices.
One 10/100 Ethernet (RJ-45) for I...
Compatibility: This docking station is compatible with the following systems:
Latitude E5510, E5520, E6220, E6320
Precision M4400, M4500, M4700, M6400, M6500, M6600, M6700
Ports Spec: 1 x serial - RS-232 - 9 pin D-Sub (DB-9)
1 x parallel - 25 pin D-Sub (DB-25)
1 x keyboard - generic - 6 pin mini-DIN (PS/2 style)
2 x USB - 4 pin USB Type A
1 x network - RJ-45
1 x display / video - VGA - 15 pin HD D-Sub (HD-15)
2 x display / video - DVI-Digital - 24 pin digital DVI
2 x display / video - 20 pin DisplayPort
1 x mouse - generic - 6 pin mini-DIN (PS/2 style)
Audio
Compatibility: EliteBook 8540p Notebook PC
EliteBook 8540w Mobile Workstation
ProBook 6440b Notebook PC
ProBook 6540b Notebook PC
ProBook 6545b Notebook PC
Ports Spec: 6 x USB 2.0 ports (5 Always-On, 1 powered)
1 x eSATA adapter
1 x Line-in jack
1 x Audio-out (headphone) jack
2 x DisplayPort
1 x VGA
2 x DVI-D
AC adapter connector with light
1 x Mouse connector
1 x Keyboard connector
1 x Parallel port
1 x Serial port
1 x Monitor stand port
1 x RJ-45 (network) jack
Dimension: 2.60" Height x 10.65" Width x 10.24" Depth
Compatibility: HP EliteBook Notebooks:
8440p
8540p
HP EliteBook Mobile Workstations:
8540w
8740w
8440w
HP ProBook Notebooks:
6450b
6455b
6550b
6555b
Ports Spec: 5 x 4-pin Type A USB 2.0 USB
1 x 8-pin Powered USB 2.0
1 x mini-DIN Headphone
1 x Mini-phone Audio In
1 x 25-pin DB-25 IEEE 1284 (EPP/ECP) Parallel
1 x 9-pin DB-9 RS-232 Serial
1 x 15-pin HD-15 VGA
2 x 20-pin Display Port Digital Audio/Video
2 x 24-pin DVI-D Digital Video
1 x eSATA
1 x RJ-45 Network
1 x 6-pin mini-DIN (PS/2) Keyboard
1 x 6-pin mini-DIN (PS/2) Mouse
Dimension: 10.24" Height x 2.60" Width x 10.65" Depth
Ports Spec: Convenient eject button for one-step system removal USB Ports:
Port Replicator: 3x USB 2.0, 1x USB 3.0
Mini Dock: 5x USB 2.0, 1x USB 3.0
Mini Dock Plus (90W & 170W): 6x USB 2.0, 1x USB 3.0
Multiple video ports:
Port Replicator: 1x VGA
Mini Dock: 1x VGA, 1x DP
The video controller allows for any two video ports to be used simultaneously.
Compatibility: Latitude E4200
Latitude E4300
Latitude E4310
Latitude E5400
Latitude E5410
Latitude E5420
Latitude E5430
Latitude E5440
Latitude E5500
Latitude E5510
Latitude E5520
Latitude E5530
Latitude E5540
Latitude E6220
Latitude E6230
Latitude E6320
Latitude E6330
Latitude E6400
Latitude E6400 ATG
Latitude E6400 XFR
Latitude E6410
Latitude E6410 ATG
Latitude E6420
Latitude E6420 ATG
Latitude E6420 XFR
Latitude E6430
Latitude E6430 ATG
Latitude E6430s
Latitude E6440
Latitude E6500
Latitude E6510
Latitude E6520
Latitude E6530
Latitude E6540
Latitude E7240
Latitude E7440
Ports Spec: 1 x display / video - DisplayPort
1 x display / video - DVI-Digital - 18 pin digital DVI (Single-Link)
1 x display / video - VGA - 15 pin HD D-Sub (HD-15)
2 x SuperSpeed USB 3.0 - 9 pin USB Type A
1 x eSATA / USB 2.0 - 11 pin USB/eSATA
3 x USB 2.0 - 4 pin USB Type A
1 x netwo...
