Specification: Installed whole system maximum rack depth: 20.5"
Installed whole system minimum rack depth: 3"
Style: Wall Mounted
Factory preset rack depth: 10.42"
Cable Access Hole Measurement: 9.812" x 2.35" (L x W)
Grounding lug: Front and Back door frames
CERTIFICATIONS
NOM (Mexico): Tested to NOM (Mexico)
Approvals: EIA-310-E, IEC 60297-3-100, IP20 Protection Rating, RoHS
Features: • Industrial power supply with integrated DIN-Rail mount
• Provides up to 150W of power (52V DC, 2.89A)
• Supported output voltage 48 – 56V DC
• High efficiency 93% and low power dissipation
• 150% peak load capability
• Built-in active Power Factor Controller (PF > 0.96)
• Cooling by natural air convection
• Protections: Overload,
Wavelength: TX wavelength*
- Blue latch: 1270 nm
- Red latch: 1330 nm
*Must be used in pairs (blue latch and red latch).
RX wavelength*
- Blue latch: 1330 nm
- Red latch: 1270 nm
*Must be used in pairs (blue latch and red latch).
Security: • Captive Portal Authentication
• Access Control
• Maximum Number of MAC Filter: 4,000
• Wireless Isolation Between Clients
• WPA-Personal/Enterprise, WPA2-Personal/Enterprise
• 802.1X Support
• VLAN
Specifications: Standards and Protocols: IEEE Std 802.3, 802.3ab, 802.3bz, 82.3an
Power Supply: 3.3V
Max. Cable Length:
- 100BASE-TX: UTP cat .5 or above (max. 100m)
- 1000BASE-T/2.5GBASE-T/5GBASE-T: UTP cat.5e or above (max. 100m)
- 10GBASE-T: UTP cat.6a or above (max. 30m)
Data Rate: 10.3 Gbps
Port Type: 1 x 10G RJ45 Port
Safety & Emission: FCC, CE, RoHS
Environment:
- Operating Temperature: 0 - 70 °C (32 - 158 °F)
- Storage Temperature: -40 - 85 °C (-40 - 185 °F)
Features: Support 10GBASE-T, 5GBASE-T, 2.5GBASE-T, 1000BASE-T, and 100BASE-TX
Transmit data up to 30m* at 10 Gbps (UTP cat.6a or above)
Support DDM (Temperature and Voltage)
Hot-Pluggable SFP+ Footprint Features
Support TX Disable function
Commercial Product Operating Temperature Range: 0-70°C
Fully Metallic Enclosure for Low EMI
