Specification: Back Door Construction: Solid Steel
Frame Type: Enclosed Cabinet
Front Door Construction: Steel Mesh
Front Door Key Lock: Yes
Front Door Reversible and / or Removable: No
Rack Type: 4-Post
Side Panel Construction: Steel Mesh
Side Panels Reversible and / or Removable: Removable, Reversible
Style: Wall-Mount
Wall mountable: Yes
Enclosure Type: Steel
External Depth: 25.6 in [65 cm]
External Height: 25.1 in [63.7 cm]
External Width: 23.6 in [60 cm]
Internal Depth: 24.8 in [63 cm]
Internal Height: 21.3 in [54 cm]
Internal Width: 17.7 in [45 cm]
Maximum Mounting Depth: 24 in [61 cm]
Minimum Mounting Depth: 2.4 in [6 cm]
Specification: Rail OEM: All Purpose
Server Compatibility: Apple, Dell, HP and IBM
Rack Type:
Mounts in any type of 4Post rack
2Post versions are also available
Hole Type:
Compatible with the industry standard 3/8" square hole racks
Cage nuts included for square hole mounting
Compatible with all standard round (non-threaded) holes
Compatible with all standard threads including 10-32, 12-24 and metric M6
Rail Type: Fixed
Mounting Depth Range: 0" to 31.75" (0 mm to 806.5 mm)
Equipment Width:
Maximum: 17.625 (448 mm)
1U Minimum: 16.625" (422 mm)
Equipment Depth:
The rack rails support flange is 23 1/2" (597 mm) long.
The rack rail will support servers computers or equipment up to 35" (889 mm) deep.
Overall Installation Depth: Maximum overall depth is the same as th...
