Specifications: Connector(s):
1 - Drive Connectors: M.2 (PCIe, SATA, M-Key, NGFF)
1 - Host Connectors: USB 3.1 USB Type C (10 pin, Gen 2, 10 Gbps)
Interface: USB 3.1 Gen 2
Bus Type: USB 3.2 Gen 2 10Gbps
Number of Drives: 1
Drive Size: 22 mm - M.2 NVMe
Compatible Drive Types: M.2 (PCIe, NVMe, M-Key, NGFF)
Drive Installation: Fixed
Compatible Drive Types: M.2 SATA (NGFF, B+M-Key)
Supported Drive Height(s):
2230
2242
2260
2280
Chipset ID: Realtek - RTL9210B
1 - LED Indicators: Power & Activity
Maximum Data Transfer Rate: 10 Gbps
Type and Rate: USB 3.2 Gen 2 - 10 Gbit/s
UASP Support: Yes
TRIM Support: Yes
4Kn Support: Yes
Type and Rate: NVMe (PCIe Gen 3)
Insertion Rating:
USB-C: 10,000 cycles
M.2: 60 Cycles
General Specifications: Fully compatible with M.2 SATA, AHCI and PCIe NVMe based drive...
Specifications: Product name: 8 Bay Hard Drive RAID Enclosure for 2.5/3.5 inch SATA SSD/HDD
Product function: Data transfer read&write&backup
Model number: K8AA
Package size 45.9*45.9*26.4CM/ 18*18*10.3inch
Product size 13.7*13.6*5.9inch
Material Aluminum
Color Black
Weight 8.13kg
Supported hard disk 2.5/3.5 SATA HDD/SSD & mSATA
Hardware Interface FireWire eSATA, USB 3.0 Type C
Power Source 350W
Transfer rate Max 5Gbps
Max capacity 16TB*8=128TB
Features built-in smart temperature management system, Lcd finger-touch screen display the working temperature and working time duration
Specifications: Support Drive Size: 4 x M.2 SSD (2230~22110)
Compatible Drive Type: NVMe PCIe Gen 4x4
Number of Drives: 4
Support Drive Length: 30mm - 110mm
Drive Bay: 1 x 5.25" half height bay
Host Interface: 4 x OCuLink(SFF-8612), pin-out defined by SFF-9402 Rev 1.1
Power Input: 2 x 15pin SATA power connector
Transfer Rate: Up to 64Gbps (Depending on SSD Speed)
Support SSD Capacity: No Limitation
Drive Cooling (Active): 2 x 40*40*20mm Fan
Structure / Material: Full Metal
Drive Security: 2 segment key lock
Support Hot-Plug: Yes (host must support hot-plug function)
Drive Activity LED Indication: Drive power: solid green; Drive access: flashing green
M.2 Connector Insertion Rate: 5,000
Humidity: 5%~65% RH
Operating Temperature: 0°C to 60°C (32°F to 140...
Specifications: Whether you are a designer, business traveler, photographer, videographer, or content creator, ORICO USB4 Enclosures allows you to confidently deal with large amounts of video, images, files, and digital data quickly and with ease. Expand your digital storage, making your work and life easier and more efficient.
Specifications: Device Support: SATA III/II/I HDD or SSD or Hybrid
Device Size: 3.5" or 2.5" SATA HDD/SSD/Hybrid
Internal Interface: Standard SATA
External Interface: USB 3.1 Type C
Interface Cable x2:
USB Type-C to Type-C (for system with Type-C port)
USB Type-C to Type-A (for system with Type-A port)
USB cable Length: 30 inches / 800mm each
HD Capacity: Up to 12TB
Material: Aluminum Casing, ABS Tray
AC Adapter Output: 12VDC, 2A.
