Specifications: Audio: Supports high-definition audio (HD) 5.1/6.1/7.1 surround sound: Dolby TrueHD, DTS-HD Master Audio LPCM channels up to 7.1 channels 192 kHz
Operating Humidity: 0 to 80% relative humidity
Operating Temperature: 32° to 122° F (0° to 50° C)
PoE: Complies with IEEE 802.3at standard, Class 4;
Power: Normal input: 48 VDC;
Input Range: 36 to 57 VDC
Power: (1) External 5 VDC, 3 A
Power Consumption: POE: 10.5 W
Storage Temperature: -4° to +140° F (-20° to +60° C)
User Controls:
B1: Set/Reset Pushbutton;
B2: Function Selection Pushbutton;
Rotary switch: Select from 16 Video Channels (HEX 0–F), Paired TX and RX units must use the same channel
Specifications: Supported Resolutions: HDMI 1280x720 (720p) / 60Hz
LED Indicators:
- 1 x Power LED
- 2 x Composite Video, S-Video LED
Input Voltage: 100 - 240 AC
Humidity: 10~85% RH
Operating Temperature: 0°C to 45°C (32°F to 113°F)
Storage Temperature: -10°C to 80°C (14°F to 176°F)
Connector A: 1x Composite Video (1 x RCA) Female Input
1x S-Video (4 pin, Mini-DIN) Female Input
