PCI Express 3.0 x16: AMD B550 Chipset
1 x PCIe 3.0 x16 slot (supports x4 mode)*
3 x PCIe 3.0 x16 slots (support x1 mode)*
*PCIE 3.0 X16_4 will run x1 mode when any of the PCIE 3.0 x16_2/3/5 slots is occupied.
**Support PCIe bifurcation for RAID on CPU function.
Audio Channels: Realtek ALC897/887 7.1 Surround Sound High Definition Audio CODEC
- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
- Supports up to 24-Bit/192 kHz playback
Audio Features
- Audio Shielding
- Rear optical S/PDIF out port
- Premium Japanese audio capacitor...
Part Number: 6 x USB-A
2 x DisplayPort
2 x HDMI
1 x 4-Pole Phone Jack
1 x Type-C ( Connect to laptop )
1 x RJ45 Gigabit Ethernet
1 x DC Power Jack Port
Compatibility: Compatible with Apple M1/M2 and Intel Macs (with macOS 10.14 or later) . Support Windows 11, 10, 8.x, and 7, ChromeOS 100+.Not supported Surface RT, Linux/Unix (see Display Link website for more details).Dock does not charge host PC.
Not Compatible :
Windows XP (64-bit) and Surface RT, Linux, Unix, Mac OS X
Ports Spec: Our universal docking stations compatible USB 3.0/USB-C/Thunderbolt 3 Laptop, provides dual HDMI or DisplayPort video outputs, wired Gigabit Ethernet, 3.5mm Audio out and Mic in jack, and six USB 3.0 ports. Come with both USB 3.0 and USB-C cables for flexible host connectivity.
Specifications: Audio Fiber Cable is a must-have cable for multi-channel (5.1, 6.1, and 7.1) Dolby AC-3 / DTS decoding for a variety of short-range signal transmissions with fiber optic digital terminals, communication and audio equipment amplifiers, DVD players, VCR, CD player, MD, AMP, PLAYER, mini disc, digital to analog converter, satellite receiver and optoelectronic device, switch, 1394 card, fiber optic sound card, cable set top box, digital camera, copier, printer, printing equipment, light sensor And industrial equipment, automobiles, medical equipment and power systems
Name: Metal Digital Audio Fiber Cable
Color: gold / black
Wire: outer diameter OD2.2/5.0MM
Core material: fiber
Wire: Aluminum alloy
Interface technology: gold plated
Memory Standard: 4 x DIMM, Max. 192GB, DDR5 7200+(OC)/7000(OC)/6800(OC)/6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600/ 5400/ 5200/ 5000/ 4800 Non-ECC, Un-buffered Memory*
* Supported memory types, data rate(Speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information refer to www.asus.com for memory support list.
* Non-ECC, un-buffered DDR5 memory supports On-Die ECC function.
Number of Memory Slots: 4x288pin (DDR5)
Audio Chipset: Realtek 7.1 Surround Sound High Definition Audio CODEC*
- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
- Supports up to 24-Bit/192 kHz playback
Audio Features
- Audio Shielding
- Premium audio capacitors
- Dedicated audio PCB layers
* A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound a...
Memory Standard: DDR5 7200(OC)/7000(OC)/6800(OC)/6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600/ 5400/ 5200/ 5000/ 4800MHz Non-ECC, Un-buffered Memory*
Dual Channel Memory Architecture
Supports Intel® Extreme Memory Profile (XMP)
OptiMem II
* Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists), and memory frequency support depends on the CPU types.
Number of Memory Slots: 4x288pin (DDR5)
Audio Chipset: Realtek S1220A 7.1 Surround Sound High Definition Audio CODEC*
- Impedance sense for front and rear headphone outputs
- Internal audio Amplifier to enhance the highest quality sound for headphone and speakers
- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
- High quality 120 dB SNR stereo playback output and 113 dB SNR recording input (Line-in)
- Supports up to 32-Bit/192 kHz playback*
Audio Fea...
Specifications: Audio Fiber Cable is a must-have cable for multi-channel (5.1, 6.1, and 7.1) Dolby AC-3 / DTS decoding for a variety of short-range signal transmissions with fiber optic digital terminals, communication and audio equipment amplifiers, DVD players, VCR, CD player, MD, AMP, PLAYER, mini disc, digital to analog converter, satellite receiver and optoelectronic device, switch, 1394 card, fiber optic sound card, cable set top box, digital camera, copier, printer, printing equipment, light sensor And industrial equipment, automobiles, medical equipment and power systems
Name: Metal Digital Audio Fiber Cable
Color: gold / black
Wire: outer diameter OD2.2/5.0MM
Core material: fiber
Wire: Aluminum alloy
Interface technology: gold plated
Memory Standard: DDR4 3200 / 3000 / 2933 / 2800 / 2666 / 2400 / 2133 *
* Actual memory data rate depends on the CPU types and DRAM modules, for more information refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
Number of Memory Slots: 2x288pin (DDR4)
Audio Chipset: Realtek 7.1 Surround Sound High Definition Audio CODEC*
* A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.
PCI Express 4.0 x16: 1 x PCI Express 4.0 x16
* Actual support may vary by CPU.
Audio Chipset: Sound Blaster Acoustic Engine, Super X-Fi
SNR: 114dB
Operating Systems Supported: Windows® 10 Ver 1703, macOS 10.15 and above, Windows® 11
System Requirements: Windows® OS
Intel® Core™i3 or AMD® equivalent processor
Intel, AMD, or 100% compatible motherboard
Microsoft® Windows 11, Windows 10 32 / 64-bit Ver 1703 or higher
> 4 GB RAM
> 4 GB of free hard disk space
USB 2.0 / USB 3.0 port
macOS
macOS X® 10.15 or higher
Supports Intel-based and Apple CPU chipsets
> 4 GB RAM
USB 2.0 / USB 3.0 port
PS5
Firmware Version 20.02-2.26.00.00-00.00.00.0.1 or later
Available USB port
Audio Balance feature requires a HDMI to Optical converter (not included)
PS4
Firmware Version 5.0 or later
Available USB port
Available Optical-out port (for Audio Balance)
Nintendo Switch
Switch OS 5.0 or later
Available 3.5 mm headphon...
