Specifications: • Standard 2.5" IDE storage device form factor (100.2mm x 69.9mm x 9.8mm)
• LED indicators: Power On, Master and Slave Card Detect, and Disk Activity
• Can be a primary bootable device containing the OS and applications (depends on CF card specifications)
• Transparent to operating system and does not require any drivers
• Supports Microsoft Windows 2000, XP 32/64-bit, Server 2003 32/64-bit, Vista 32/64-bit, Server 2008 32/64-bit and Linux operating systems
• Power supply via IDE interface (44-pin SFF IDE connector, +5V)
IDE Interface
• 44-pin SFF (Small Form Factor) IDE connector
• Supports Ultra-DMA IDE Interface
• Does not support hot swap on the IDE interface
CF Interface
• 2 CF card slots (Master/Slave) supporting CF Type I form factor
• Supports PIO mode, DMA and Ultra-DMA mode with data transfer rate u...
Specifications: Industry Standards:
- USB 3.0 Specification Rev. 1.0
- USB Battery Charging Specification Rev. 1.2 (Apple Mode only)
- PCI Express Base Specification Rev. 2.0
- Intel xHCI Specification Rev. 1.0
Interface: USB 3.0
Connector Type(s): 1 - PCI Express x4 Male
External Ports: 4 - USB 3.0 A (9 pin; SuperSpeed) Female
Internal Ports:
- 1 - LP4 (4 pin; Molex Large Drive Power) Female
- 1 - SATA Power (15 pin) Plug
Maximum Cable Length: 9.8 ft [3 m]
Maximum Data Transfer Rate: 5Gbps per 2 ports - 10Gbps Total
Type and Rate: USB 3.0 - 5 Gbit/s
UASP Support: Yes
Specifications: Output Power: 650W
Form Factor: External
Input Voltage: 110V AC; 220V AC
Number of +12V Rails: 1
Output Voltage:
12V DC @ 17.25A
-54V DC @ 12A
Dimensions: 1.70" x 17.40" x 7.20"
Weight (Approximate): 8.38 lbs.
Package Content:
H3C RPS 800 Redundant Power Supply
Power Cord
Front and Rear Mounting Brackets
Features: Product Type:Router Chassis
Ethernet Technology:Gigabit Ethernet
Number of Total Expansion Slots:3
Form Factor:Rack-mountable
Number of Network (RJ-45) Ports:6
Total Number of Ports:6
VoIP Supported:No
Expansion Slot Type:Shared Port Adapter
Product Name:ASR1002-X System
Flash Memory:4 GB
Standard Memory:4 GB
Ports Spec: AC Adapter Input: 100-240V, 50/60Hz, 0.8A; Output: 5V, 4A, 6 ft.
Dock Connectors: 2 x USB3.0. 2 x 3.5mm Stereo, 4 x USB2.0, RJ45 LAN, DVI-I, HDMI
CONNECTIONS:
Side A - Connector 1 USB 3.0 A (MALE)
Side B - Connector 1 HDMI (FEMALE)
Side B - Connector 2 (2) USB 3.0 A (FEMALE)
Side B - Connector 3 DVI-I (FEMALE)
Side B - Connector 4 RJ45 (FEMALE)
Side B - Connector 5 (4) USB A (FEMALE)
Side B - Connector 6 (2) 3.5MM (FEMALE)
Package Includes:
U342-DHG-402
External Power Supply with NEMA 1-15P Plug (Input: 100-240V, 50/60 Hz, 0.8A; Output: 5V, 4A) – 6 ft.
USB 3.0 A/B Cable – 3 ft.
Driver CD
Owner’s Manual
Specifications: Chip: FT232RL + ZT213 British import best guarantee compatibility
The CONSOLE port (used for computer USB turn RJ45)
General network devices have a CONSOLE interface, this interface is used to set or more of the underlying operating equipment.
Supports USB 1.0, 1.1, and 2.0
Used for CISCO routers and switches and AP wireless router
Apply to WIN 7 32 bit, Windows 7 64 - bit, Windows XP MAC Ann table, etc
Compatibility: OS Compatibility
Windows 10 (32-bit or 64-bit), 8.1 (32-bit or 64-bit), 7 (32-bit or 64-bit)
macOS X 10.10 (Yosemite), macOS 10.11 (El Capitan), macOS 10.12 (Sierra)
Ports Spec: 2 x DisplayPort Female
1 x Ethernet Gigabit Female
1 x USB Type-A (9 pin) USB 3.0 Male
Ports Spec: 1 x USB-C 5V/3A 5Gbps Port
1 x USB 3.0 2.1A Fast-Charging Port
1 x 3.5mm Combo Microphone & Headphone Jack
1 x USB-C Host Port (up to 60W PD)
1 x HDMI
1 x DisplayPort++
1 x Gigabit Ethernet
4 x USB 3.0 / 0.9A Ports
