Specifications: Dimensions: 16.51mm x 10.16mm
Type: Compliant to TPM Main Specification, Family "2.0", Level 00, Revision 01.16
- SPI interface
- Meeting Intel TXT, Microsoft Windows and Google Chromebook certification criteria for successful platform qualification
- Random Number Generator (RNG) according to NIST SP800-90A
- Full personalization with Endorsement Key (EK) and EK certificate
- Standard (-20..+85°C) and Enhanced temperature range (-40..+85°C)
- PG-VQFN-32-13 or PG-UQFN-32-1 package
- Pin compatible to OPTIGA TPM SLB 9670 TPM1.2 version
- Optimized for battery operated devices: low standby power consumption (typ. 110µA)
- 24 PCRs (SHA-1 or SHA-256)
- 7206 Byte free NV memory
- Up to 3 loaded sessions (TPM_PT_HR_LOADED_MIN)
- Up to 64 active sessions (TPM_PT_ACTIVE_SESSIONS_MAX)
- Up to 3 loaded transient Objects (...
Features: Connectors: Rns J45 Frame Lock, RJ-45 Frame Lock, and BNC Genlock
Thermal Solution: Passive
System Interface: Any available PCIe or PCI expansion slot
Power: 6-pin or SATA power cable
Maximum Power Consumption: 12 W
Dimensions: 6.15 x 4.37"
Computer Connections: Ports: 4
DP/HDMI Univ Video (1): 2
Keyboard and Mouse: 1 x USB 2.0 Type B
DPP - USB 2.0 Type B: 1
Analog Audio: 1 x 3.5mm Speaker
Video Resolution: UHD 4K (3840x2160) @ 60Hz
Console Connectors: DP/HDMI Univ Video (1): 2
Keyboard and Mouse: 2 x USB 2.0 Type A
DPP - USB 2.0 Type A: 1
Analog Audio: 1 x 3.5mm Speaker
