Specifications: Device Control:
Sony compatible RS422 deck control ports. Serial ports TxRx direction reversible under software control.
Supported Codecs:
AVC-Intra, AVCHD, Canon XF MPEG2, Digital SLR, DV-NTSC, DV-PAL, DVCPRO50, DVCPROHD, DPX, HDV, XDCAM EX, XDCAM HD, XDCAM HD422, Apple ProRes 4444, Apple ProRes 422 HQ, DNxHR & DNxHD, Apple ProRes 422, Apple ProRes LT, Apple ProRes 422 Proxy, Uncompressed 8-bit 4:2:2, Uncompressed 10-bit 4:2:2, Uncompressed 10 bit 4:4:4.
Software Included: Media Express, Disk Speed Test, LiveKey, Blackmagic Desktop Video Utility and Blackmagic driver on Mac OS and Windows. Media Express, Blackmagic Desktop Video Utility and Blackmagic driver on Linux.
Internal Software Upgrade: Firmware built into software driver. Loaded at system start or via updater software.
Physical Installation: PCI Express 4...
Specifications: Hardware
Audio: Yes
Converter Type: Format Converter
Industry Standards: MPEG4 (H.264)
Performance
Audio Specifications: 2-channel stereo audio
Maximum Analog Resolutions: 1920 x 1200 60 FPS
Supported Resolutions: 1920 x 1200, 1920 x 1080, 1280 x 720, 1024 x 768, 800 x 600
Wide Screen Supported: Yes
Connector(s)
Connector A:
- 1 x 3.5 mm Mini-Jack (3 Position) Female Input
- 1 x DVI-I (29 pin) Female Input
Connector B: 1 x USB Type-B (9 pin) USB 3.0 Female
Power
Power Source: USB-Powered
Environmental
Humidity: 20% to 80% (non-condensing)
Operating Temperature: 0°C to 40°C (32°F to 104°F)
Storage Temperature: -5°C to 40°C (23°F to 105°F)
Physical Characteristics
Product Height: 0.96"
Product Length: 3.63"
Product Width: 2.41"
Product Weight: 3.60 oz.
System Requirements: OS Compatibility: Windows 10, ...
Specifications: Active or Passive Adapter: Active
AV Input: HDMI
AV Output: Audio RCA, Composite
Industry Standards: Standard HDMI, DVI 1.0
Audio Specifications:
Input - LPCM 2Ch, 48kHz
Output - Stereo L/R
Supported Resolutions:
Input
TV - 1080p, 720p, 576p, 480p @ 60Hz
PC - 1920x1080, 1280x800, 1280x768, 1224x768, 800x600, 640x480 @ 60Hz
Output: 480i, 576p
Input Current: 0.4 A
Input Voltage: 100 ~ 240 AC
Output Current: 2000 mA
Output Voltage: 5 DC
Plug Type: M
Power Source: AC Adapter Included
Specifications: Color: Black
Enclosure Type: Steel
LED Indicators: 1 x Red Power LED
Video Frequency: 50/60Hz
Maximum Digital Resolutions: 1900x1200
Output Signal: DisplayPort
Power COnsumption : 5W Max
Power Adapter Included: Yes
Input Voltage: 110 ~ 240 AC
Input Current: 0.5
Output Voltage: 5 DC
Output Current: 2
Center Tip Polarity: Positive
Humidity: 5% to 90% RH (no condensation)
Operating Temperature: 0 degree C to 70 degrees C (32 degrees F to 158 degrees F)
Storage Temperature: -10 degrees C to 80 degrees C (14 degrees F to 176 degrees F)
