Specifications: Glide Wall Mount will be hidden behind display in most cases when used with screen size of 46" or greater; when used with screens smaller than 46", the mount may be visible
Mounting holes must fit within spacing range below:
Horizontal = 100 mm (min.) to 400 mm (max.)
Vertical = 100 mm (min.) to 400 mm (max.)
Includes low-profile lift module, mounting template, tilt brackets, installation and mounting hardware, cable management hardware
Specifications: Includes Includes: 10" and 34" Wall Tracks with two black track covers, LX Wall Mount LCD Arm, LX Keyboard Arm, wrist rest, mouse pad, mouse holder, Small CPU Holder, two 10" Cable Channels, mounting kits for hollow-wall and wall-stud installation
Quality Tested: 10,000-cycle test applied to lift mechanism, ensuring years of trouble-free height adjustment
Polished aluminum construction offers greater durability and enhanced aesthetics
Snap-fit cap secures interface of arms to extensions for greater stability
Weight Capacity: display = 7-25 lbs (3.2-11.3 kg); keyboard = 5 lbs (2.2 kg); CPU = 50 lbs (22 kg). With monitors greater than 20 lbs (9.1 kg) in weight, the vertical range of motion may be reduced up to 4.5" (11 cm) for a total height range of 8.5" (22 cm)
Mounting Standards: VESA FDMI MIS...
Specifications: Includes height-adjustment column, desk clamp, LCD pivot, worksurface, large keyboard tray
NOTE: Extra-long cables may be required to span between standing and sitting heights
Weight Capacity: Maximum total load on height-adjustment assembly = 29 lbs (13.2 kg). LCD weight = 16-28 lbs (7.3-12.7 kg), worksurface = 5 lbs (2.3 kg), keyboard tray = 5 lbs (2.3 kg). For proper operation the total weight of components when added together should not exceed 29 lbs (13.2 kg)
Lift Range: LCD and keyboard adjust 18" (46 cm) in tandem; LCD adjusts 4.8" (12.2 cm) independently; maximum LCD height adjustment = 22.8" (58 cm). The worksurface restricts the vertical travel range of the LCD lift pivot; height adjustment of LCD without worksurface is 5" (13 cm)
Mounting Standards: VESA FDMI, MIS-D, 75/100, C (hole pattern = 100 ...
