PC Connectors: Video Input: (1) HDMI female, (1) DisplayPort female
Serial Control Port: (1) DB9 female
Link Port: (1) RJ-45 female
USB: (1) USB Type B female
Audio: (1) Line in, (1) Line out;
Local Video Output: (1) HDMI female, (1) DisplayPort female
Console Connectors: Video Output: (2) HDMI female
Serial Control Port: (1) DB9 male
Link Port: (1) RJ-45 female
USB 2.0: (4) USB Type A female
Audio: (1) Mic In, (1) Speaker Out
Video: Video Input:
Interfaces: 1 x HDMI Type A Female (Black)
Impedance: 100 O
Max. Distance: 3 m
Video:
Max. Data Rate: 10.2Gbps (3.4Gbps per lane)
Max. Pixel Clock: 340 MHz
Compliance: HDMI (3D, Deep Color, 4K), HDCP2.2 Compatible, Consumer Electronics Control (CEC)
Max. Resolutions / Distance: Up to 4K@70m (Cat 5e/6) / 100m (Cat 6a/ATEN 2L-2910 Cat6); 1080p@100m (Cat 5e/6/6a); *4K supported: 4096 x 2160 / 3840 x 2160 @ 60Hz (4:2:0); 4096 x 2160 / 3840 x 2160 @ 30Hz (4:4:4)
Audio: Audio Input: 1 x HDMI Type A Female (Black)
Other Connector: Unit To Unit: 1 x RJ-45 Female
Firmware Upgrade: 1 x Mini Stereo Jack Female (Black)
Power: 1 x DC Jack (Black) with locking
Specifications: MCX is a next-generation AV-over-IP solution from Black Box. MCX distributes and extends 4K 60 Hz video and audio over IP and is made for 10-Gbps network infrastructures.
Uncompressed 4K 60 Hz 4:4:4 Video
MCX delivers the video quality high-end AV applications require to display eye-catching content: It extends uncompressed 4K 60 Hz 4:4:4 video to an unlimited number of displays without sacrificing latency, video quality or bandwidth. Even better, it supports up to 10-bit HDR using Software-Defined Video over Ethernet (SDVoE) - the latest software-based AV-over-IP platform for extension and control of AV systems on Ethernet or fiber networks.
Easy, Flexible Deployment
This video extension system is easy to install on a modern network. MCXS7 can be deployed on 10G networks over copper Ethernet.
...
Type: StarTech.com 4K HDMI Splitter 1 In 2 Out - 4K 30Hz HDMI 1.4 2 Port Video Splitter Box -with high speed HDMI cable, USB power cable - Black (ST122HD4KU), HDMI
