Specifications: Display Style: Signal Booster
Color: Black
Connector A: DVI-I (FEMALE)
Connector B: DVI-I (FEMALE)
Interface: DVI
Package Contents: B120-000 DVI Dual Link Signal Extender
External Power Supply ( Input: 100-240V, 50/60Hz, 0.5A Output: 5V, 2A)
Screwdriver for Equalization adjustment
Owner's Manual
Specifications: Frequency 4.9 ~ 5.9GHz (Includes non-DFS and DFS Frequency Bands)
Antenna Type High Performance Internal
Range Maximum video transmission range is 200ft (60m)
Power Switch 1 x Push Button (Transmitter and Receiver)
LEDs
Power On Green / Red LED (Transmitter and Receiver)
Link Green LED (Transmitter and Receiver)
Input 5 x Green (Transmitter) 1 x Green (Receiver)
Power
Voltage 100~240v - 5V DC Jack (Transmitter), 5V DC mini USB (Receiver)
Amps Transmitter: 2A, Receiver: 1.5A
Infrared
Frequency 3ft IR Extension Cable 38kHz, 47kHz & 56kHz
Operating Temperature 0 ~ 40C
Housing
Case Plastic
Cable Connections
Input 1 x Mini USB (Female)
Security 128-Bit AES Encryption
Video Format: Video Resolution 480p, 576p, 720p, 1080i, 1080p (24/30/60fps) and 3D Support
Video Streaming <1ms Latency...
Specifications: Weight & Size:
Weight: 8.80 oz. / 250 g
Height: 3.858 in / 9.800 cm
Width: 6.26 in / 15.900 cm
Depth: 1.02 in / 2.593 cm
Storage:
16GB*
* Portion of storage occupied by system software
Expandable using USB flash or hard drives.
Wireless:
802.11ac 2x2 MIMO 2.4 GHz and 5 GHz Wi-Fi
Bluetooth 5.0 + LE
Captive Portal support
Software Updates:
SHIELD Experience Upgrades directly from NVIDIA
Voice Assistants:
Built in Voice Control
The Google Assistant
Hands-free Voice Control*
Google Home compatible (Google Assistant)**
Amazon Echo compatible (Works with Alexa)**
* Requires SHIELD Controller or Google Home Mini or Amazon Echo.
** Google ecosystem includes the Google Assistant, Google Play Movies and TV app, Google Music app, Google photos, and access to Google calendar. Amazon ecosystem include...
Specifications: Hardware
Audio: Yes
Performance
Maximum Digital Resolutions: 1920 x 1080 (1080p) at 60Hz
Supported Resolutions: 1920 x 1080, 1680 x 1050, 1600 x 1200, 1600 x 900, 1440 x 900, 1366 x 768, 1280 x 1024, 1280 x 720, 1024 x 768
Wide Screen Supported: Yes
Indicators
LED Indicators: 1 x status LED
Power
Power Source: USB-Powered
Environmental
Humidity: 0~80% RH
Operating Temperature: 0°C to 40°C (32°F to 104°F)
Storage Temperature: -20°C to 60°C (-4°F to 140°F)
Physical Characteristics
Enclosure Type: Steel
Product Height: 0.87"
Product Length: 3.15"
Product Width: 2.05"
Product Weight: 5.36 oz.
Package Contents: 1 x EDID emulator
1 x USB power cable
1 x screw driver
4 x foot pads
1 x quick start guide
