Operating Systems Supported: Windows 7, 8, 8.1, 10, 11
Windows Server 2003, 2008 R2, 2012, 2012 R2, 2016, 2019
macOS 10.10 to 12
Linux 2.6.32 and up
Specifications: Connector Type(s): 1 - PCI Express x4
Internal Ports: 2 - SFF-8087 (36 Pin, Internal Mini-SAS)
Ports: 8
Interface: SATA
Bus Type: PCI Express
Card Type: Standard Profile (LP bracket incl.)
Industry Standards: Serial ATA 3.0 specification - SATA I/II/III (1.5/3/6Gbps), PCI Express Base Specification Revision 2.0
Chipset ID: Pericom - PI7C9X2G608GP, ASMedia - ASM1061
Maximum Data Transfer Rate: 6 Gbps
TRIM Support: Yes
4Kn Support: Yes
S.M.A.R.T. Support: Yes
Type and Rate: SATA III (6 Gbps)
Port Multiplier: Yes
Bootable: Yes
Specifications: Chipset: Asmedia ASM3142
Compliance: USB 3.1 Gen 2 and PCI Express 3.0 specification
Form factor chassis installation: Full size and low-profile
Bus connector: Four lanes (4x) PCI Express
USB data transfer rate: 10Gbps / 5Gbps / 480Mbps / 12Mbps / 1.5Mbps
Power output: Up to 900mA, each USB port
Power consumption: 3W (max)
Connector:
- 1 x 15-pin, SATA power connector, Input
- 2 x 9-pin, USB 3.1 Gen 2, Type A, Female, Output
