Operating Systems Supported: Support Windows XP/Server 2003/Vista/7 /8 (32/64 bit) /MAC/linux
Compatibility: Have one of the available PCI-Express slots(PCIe x1 or above). Windows operating system support (R) XP/Server 2003/Vista/7 /8 (32/64 bit) /MAC/linux
Operating Systems Supported: Windows 7, 8, 8.1, 10, 11
Windows Server 2003, 2008 R2, 2012, 2012 R2, 2016, 2019
macOS 10.10 to 12
Linux 2.6.32 and up
Specifications: Connector Type(s): 1 - PCI Express x4
Internal Ports: 2 - SFF-8087 (36 Pin, Internal Mini-SAS)
Ports: 8
Interface: SATA
Bus Type: PCI Express
Card Type: Standard Profile (LP bracket incl.)
Industry Standards: Serial ATA 3.0 specification - SATA I/II/III (1.5/3/6Gbps), PCI Express Base Specification Revision 2.0
Chipset ID: Pericom - PI7C9X2G608GP, ASMedia - ASM1061
Maximum Data Transfer Rate: 6 Gbps
TRIM Support: Yes
4Kn Support: Yes
S.M.A.R.T. Support: Yes
Type and Rate: SATA III (6 Gbps)
Port Multiplier: Yes
Bootable: Yes
Operating Systems Supported: Windows XP, 2003 Server, Vista, 2008 Server and 7 (32/64-bit)
Specifications: Compliant with PCI Express 2.0 Supports communication speed of 2.5Gbps & 5.0Gbps Compliant with SATA 3.0 specification Compatible with SATA 6G, 3G & 1.5G Hard drive Hot-swap & Hot Plug Supports Port Multiplier FIS based switching or command based switching Supports Native Command Queuing(NCQ) Supports RAID function 0 and 1 Supports ATA/ATAPI-7 Spec, Supports ATA & ATAPI commands Supports DMA protocols, and up to UDMA 150Mbps data transfer rate Supports Master and Slave operations from a single PATA port Supports PCI Low Profile
