Specification: Pump Compatibility: D5 Pump (Gen3 D5 Pump pre-installed)
Installation Compatibility: 120/140 mm fan/radiator
Color: White
LED Type: Digital-RGB LED strip hard board (+5V, data, empty, Ground)
LED strip length: 74 mm
Number of LEDs: 7pcs
Input Voltage: +5V
Current Max: 0.21A
Wattage Max: 1.05W
Capacity: 210 ml
Materials: Acrylic
Aluminum cover
Fitting: Nickel Plated Brass
Fitting Insert: ABS
Fill Port 1 x G 1/4
No. of Inlet 2 x M24 x P1
No. of Outlet 2 x M24 x P1
Supported tube size Hard Tube: OD 16mm
Soft Tube: OD 16mm; ID 10mm
Tube Compatibility Hard Tube: PETG, Acrylic tube
Soft Tube: PVC tube
Specification: Pump Compatibility: DDC
Installation Compatibility: 120 or 140 mm fan/radiator
Seal O-Ring: DuPont VITON
Reservoir - ID: 88.62 / W: 1.78
Color: Transparent
RGB LED type: Digital-RGB (addressable)
LED Number: 5050, 12pcs
LED Electricity Spec: 5V/0.45A/2.25W
Capacity: 160ml
Materials: Acrylic body, Acrylic backplate, Steel bracket
Max Water Loop Temperature: 60?
Fill port: 1 x G 1/4
No. of inlet: 3 x G 1/4
No. of outlet: 1 x G 1/4
Package Contents: 1 x PH-R160C_02
3 x Stop Fitting G1/4 (Pre-installed)
1 x D-RGB LED Board (12 Pcs LEDs)
1 x D-RGB LED cable
1 x D-RGB LED motherboard adapter
1 x Reservoir Bracket (2x Pre-installed Rubber Pad)
2 x M4x10mm bracket screws
2 x M4x6mm LED strip screws
4 x M4 x25mm pump screws
4 x fan screws
1 x 3 mm Allen key
1 x User Manual
Specification: Pump Compatibility D5 Pump (Gen3 D5 Pump pre-installed)
Installation Compatibility 120/140 mm fan/radiator
Color Black
LED Type Digital-RGB LED strip hard board (+5V, data, empty, Ground)
LED strip length 74 mm
Number of LEDs 7pcs
Input Voltage +5V
Current Max: 0.21A
Wattage Max: 1.05W
Capacity 210 ml
Materials Acrylic
Aluminum cover
Fitting: ED Black Brass
Fitting Insert: ABS
Fill Port 1 x G ¼ Stop Fitting
Number of Inlet 2 x M24 x P1
Number of Outlet 2 x M24 x P1
Supported tube size Hard Tube: OD 16mm
Soft Tube: OD 16mm; ID 10mm
Tube Compatibility Hard Tube: PETG, Acrylic tube
Soft Tube: PVC tube
