PC CHIPS m863g 462(A) SiS 741GX Micro ATX AMD Motherboard
- SiS 741GX
- Athlon XP / Athlon / Duron
- DDR 333
Specs
Reviews (28)
Any questions? Our AI beta will help you find out quickly.
Try me now
Learn more about the PCCHIPS m863g
| Brand | PC CHIPS |
|---|---|
| Model | m863g |
| CPU Socket Type | 462(A) |
|---|---|
| CPU Type | Athlon XP / Athlon / Duron |
| FSB | 333/266 MHz |
| Chipset | SiS 741GX |
|---|---|
| South Bridge | SiS 963L |
| Number of Memory Slots | 2x184pin |
|---|---|
| Memory Standard | DDR 333 |
| Maximum Memory Supported | 2GB |
| AGP Slots | 1 x AGP 4X / 8X |
|---|---|
| PCI Express x16 | None |
| PCI Slots | 2 x PCI Slots |
| Other Slots | 1x CNR |
| PATA | 2 x ATA100 4 Dev. Max |
|---|
| Onboard Video Chipset | SiS Mirage Graphics |
|---|
| Audio Chipset | AC97 Codec |
|---|---|
| Audio Channels | 2 Channels |
| LAN Chipset | Realtek 8201BL PHY |
|---|---|
| Max LAN Speed | 100Mbps |
| Back I/O Ports | 1 x COM (Serial Port) / 1 x D-Sub / 1 x LPT (Parallel Port) / 2 x PS/2 / 3 x Audio Jacks / 4 x USB 2.0/1.1 |
|---|---|
| PS/2 | 2 |
| COM | 1 |
| LPT | 1 |
| Video Ports | D-Sub |
| USB 1.1/2.0 | 4 x USB 2.0 |
| Audio Ports | 3 Ports |
| Onboard USB | 2 x USB 2.0 |
|---|
| Form Factor | Micro ATX |
|---|---|
| Dimensions (W x L) | 9.6" x 7.9" |
| First Listed on Newegg | March 26, 2004 |
|---|
