Learn more about the PowerColor AXRX 6800XT 16GBD6-3DHR/OC
ModelBrand | PowerColor |
---|
Series | RED DRAGON |
---|
Model | AXRX 6800XT 16GBD6-3DHR/OC |
---|
InterfaceInterface | PCI Express 4.0 |
---|
ChipsetChipset Manufacturer | AMD |
---|
GPU Series | AMD Radeon RX 6000 Series |
---|
GPU | Radeon RX 6800 XT |
---|
Game Clock | OC: up to 2065 MHz STD/Silent: up to 2015 MHz |
---|
Boost Clock | OC: up to 2310 MHz STD/Silent: up to 2250 MHz |
---|
Stream Processors | 4608 Stream Processors |
---|
MemoryEffective Memory Clock | 16.0 Gbps |
---|
Memory Size | 16GB |
---|
Memory Interface | 256-Bit |
---|
Memory Type | GDDR6 |
---|
3D APIDirectX | DirectX 12 Ultimate |
---|
PortsHDMI | 1 x HDMI 2.1 |
---|
DisplayPort | 3 x DisplayPort 1.4 |
---|
DetailsMax Resolution | 7680 x 4320 |
---|
Eyefinity Support | Yes |
---|
Virtual Reality Ready | Yes |
---|
Cooler | Triple Fans |
---|
Thermal Design Power | 300W |
---|
System Requirements | Minimum System Power requirement: 750W |
---|
Recommended PSU Wattage | 700W |
---|
Power Connector | 2 x 8-Pin |
---|
FeaturesFeatures | AMD FidelityFX AMD FreeSync Technology
AMD RDNA 2 Architecture
GDDR6 Memory
HDMI 2.1 VRR
Microsoft Windows 10 Support
Mute Fan Technology
PCIe 4.0 Support
Radeon Anti-Lag
Radeon Chill
Radeon Image Sharpening
Radeon VR Ready Premium
Radeon WattMan
UEFI Support |
---|
Form Factor & DimensionsMax GPU Length | 310 mm |
---|
Card Dimensions (L x H) | 12.20" x 5.31" |
---|
PackagingPackage Contents | Accessories: Manual |
---|
Additional InformationDate First Available | June 11, 2025 |
---|
