Intel S5520HCR SSI EEB Server Motherboard Dual LGA 1366 Intel 5520 DDR3 1333
- Dual LGA 1366
- Intel 5520
- 12 x 240pin
Specs
Reviews (3)
Any questions? Our AI beta will help you find out quickly.
Try me now
Learn more about the Intel S5520HCR
| Brand | Intel |
|---|---|
| Model | S5520HCR |
| CPU Socket Type | Dual LGA 1366 |
|---|---|
| CPU Type | Dual Intel Xeon 5500/5600 Series |
| QPI | 4.8 GT/s, 5.8 GT/s, and 6.4 GT/s |
| North Bridge | Intel 5520 |
|---|---|
| South Bridge | Intel ICH10R |
| Number of DDR3 Slots | 12 x 240pin |
|---|---|
| DDR3 Standard | DDR3 1333 |
| Maximum Memory Supported | 192GB |
| PCI Express x8 | 1 x PCI Express 2.0 x8 slot (x16 mechanical) 3 x PCI Express 2.0 x8 slot (x8 mechanical) |
|---|---|
| PCI Express x4 | 1 x PCI Express 1.0 x4 slot (x8 mechanical shared with optional SAS module) |
| PCI Slots | 1 x PCI Slot |
| SATA | 6 x SATA 3.0Gb/s |
|---|---|
| SATA RAID | 0/1 |
| LAN Speed | 10/100/1000Mbps |
|---|---|
| Second LAN Speed | 10/100/1000Mbps |
| Max LAN Speed | 2 x 1Gbps |
| COM | 1 |
|---|---|
| Video Ports | D-Sub |
| USB 1.1/2.0 | 4 x USB 2.0 |
| Form Factor | SSI EEB |
|---|---|
| Dimensions (W x L) | 12.0" x 13.0" |
| First Listed on Newegg | March 18, 2010 |
|---|
