Question 1

This says SATA III, my Dell is SATA will this work?

Accepted Answer

This is a mSata drive. It is different from regular Sata. You would need to make sure your machine accepts mSata specifically.

Question 2

Will this fit in a standard wifi card location? I am trying to add it to an hp steak book instead of using the integrated 32gb harddrive. I just wanted to make sure it's going to fit in the slot assigned.

Accepted Answer

Good Afternoon

WiFi card dimensions vary, i would get with your manufacturer and see if the slot will work with as a secondary hard drive slot. And if it is SATA 2 or SATA 3

Or use google to see if anyone else has had a successful upgrade like the one you are attempting

Best of luck

Question 3

is it compatible with 13" MAc Book pro mid 2013 model?

Accepted Answer

I installed my SAMSUNG 860 EVO Series mSATA 500GB SATA III 3D NAND Internal Solid State Drive (SSD) into a DROBO 5D3 RAID, not a Mac computer, where it works well.

Question 4

will this work in my Dell XPS 12 9Q33 ?

Accepted Answer

I have no idea why it wouldn't as long as you have a sata connection available. Mounting the drive is  like any other 2.5" drive, so if you are not replacing a 2.
5" drive with it, you may need an adapter

Question 5

Will this drive work in my HP Folio13 US1020 notebook?

Accepted Answer

No it will not. This is an older technology mSATA. You need an M.2 NVMe technology for that notebook.

Question 6

What is the read/write speed on one of these?

Accepted Answer

Just the single SATA port  for this form-factor, so capped at just 550Msecond.

Brand	SAMSUNG
Series	860 EVO Series
Model	MZ-M6E500BW
Device Type	Internal Solid State Drive (SSD)
Used For	Consumer

Form Factor	mSATA
Capacity	500GB
Memory Components	V-NAND 3-bit MLC
Interface	SATA III
Controller	Samsung MJX
Cache	Samsung 512GB Low Power DDR4 SDRAM

Max Sequential Read	Up to 550 MBps
Max Sequential Write	Up to 520 MBps
4KB Random Read	QD32: Up to 97,000 IOPS QD1: Up to 10,000 IOPS
4KB Random Write	QD32: Up to 88,000 IOPS QD1: Up to 42,000 IOPS
MTBF	1,500,000 hours

Power Consumption (Idle)	50 mW
Power Consumption (Active)	Average: 2.5W Maximum: 4.5W (Burst mode)
Operating Temperature	0°C ~ +70°C
Storage Temperature	-45°C ~ +85°C
Operating Humidity	5% to 95% RH
Max Shock Resistance	1,500G & 0.5 ms (Half sine)
Max Vibration Resistance	20G

Height	4.83mm
Width	29.97mm
Depth	50.80mm
Weight	81.65g
