Brand | SAPPHIRE |
---|---|
Series | NITRO |
Model | 100406NT8GOCL |
Interface | PCI Express 3.0 |
---|
Chipset Manufacturer | AMD |
---|---|
GPU Series | AMD Radeon RX 400 Series |
GPU | Radeon RX 480 |
Core Clock | 1202 MHz |
Boost Clock | 1306 MHz |
Stream Processors | 2304 Stream Processors |
Effective Memory Clock | 1750 MHz (7.0 Gbps) |
---|---|
Memory Size | 8GB |
Memory Interface | 256-Bit |
Memory Type | GDDR5 |
DirectX | DirectX 12 |
---|---|
OpenGL | OpenGL 4.5 |
Multi-Monitor Support | 5 |
---|---|
HDMI | 2 x HDMI 2.0b |
DisplayPort | 2 x DisplayPort 1.4 |
DVI | 1 x DVI-D |
Max Resolution | 3840 x 2160 |
---|---|
Eyefinity Support | Yes |
CrossFireX Support | Yes |
TrueAudio Support | Yes |
Virtual Reality Ready | Yes |
Cooler | Dual-X fans |
Operating Systems Supported | Windows 10 Windows 7 |
System Requirements | Power Consumption: 225W 500W Power Supply (Suggestion) 1 x 8-pin AUX Power Connector CD-ROM or DVD-ROM drive for installing software PCI Express 2.0 or higher version based PC is required with one X16 lane graphics slot available on the motherboard in order for the card to be compatible with |
Power Connector | 8-Pin |
Features | AMD CrossFire FreeSync Technology AMD Eyefinity Quad HD Display (4K x 2K Support) Video Codec Engine (VCE) AMD Liquid VR Technology AMD Virtual Super Resolution (VSR) AMD TrueAudio Next Technology Dolby TrueHD and DTS-HD Master Audio Support AMD Xconnect ready DirectX 12 Optimized Radeon VR ready Premium HDR Ready Frame Rate Target Control NITRO Quick Connect system NITRO CoolTech (NCT) NITRO Free Flow Dual-X Cooling |
---|
Max GPU Length | 230 mm |
---|---|
Card Dimensions (L x H) | 9.06" x 4.96" |
Slot Width | 2 Slots |
Date First Available | February 14, 2017 |
---|
