SOYO SY-P4I 845PE ISA Socket 478 Intel 845PE ATX Intel Motherboard
- Intel 845PE
- Pentium 4 / Celeron
- DDR 333
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Learn more about the SOYO SY-P4I 845PE ISA
| Brand | SOYO |
|---|---|
| Model | SY-P4I 845PE ISA |
| CPU Socket Type | Socket 478 |
|---|---|
| CPU Type | Pentium 4 / Celeron |
| FSB | 533/400 MHz |
| Supported CPU Technologies | Hyper-Threading Technology |
| Chipset | Intel 845PE |
|---|---|
| South Bridge | Intel ICH4 |
| Onboard Video Chipset | None |
|---|
| Number of Memory Slots | 2x184pin |
|---|---|
| Memory Standard | DDR 333 |
| Maximum Memory Supported | 2GB |
| AGP Slots | 1 x AGP 2X / 4X |
|---|---|
| PCI Express x16 | None |
| PCI Slots | 4 x PCI Slots |
| Other Slots | 3x ISA |
| PATA | 2 x ATA100 4 Dev. Max |
|---|
| Audio Chipset | AC97 Codec |
|---|---|
| Audio Channels | 4 Channels |
| Max LAN Speed | 100Mbps |
|---|
| Back I/O Ports | 2 x PS/2 / 2 x USB 2.0/1.1 |
|---|---|
| PS/2 | 2 |
| COM | 1 |
| LPT | 1 |
| USB 1.1/2.0 | 2 x USB 2.0 |
| Game/MIDI Ports | 1 |
| Audio Ports | 3 Ports |
| Onboard USB | 4 x USB 2.0 |
|---|
| Form Factor | ATX |
|---|---|
| Dimensions (W x L) | 12.0" x 8.8" |
| Features | Award PCI BIOS with ACPI function Supports multiple-boot from E-IDE/SCSI/CD-ROM/FDD LS120/ZIP 2 Mb Flash ROM |
|---|
| First Listed on Newegg | December 14, 2004 |
|---|
