SSUPD Meshroom S V2 Mini-ITX Small Form Factor (SFF) Case - Full Mesh Side Panel without PCIe Riser Cable - Black Color, Tool-Free and Easy Accessibility

(13)(2) Write a Review
  • Compact 14.9 liter volume allows full-size GPU, ATX PSU, and 280 AIO cooler compatibility.
  • Support up to two 280mm radiator with extra mounting bracket.
  • Support full length GPU up to 332mm long on 3 slots mode and up to 336mm long on 4 slots mode.
  • Compatible with Mini-ITX, Mini-DTX, Micro-ATX and ATX motherboard (require extra PCIe riser cable for Micro-ATX and ATX setup)
  • Fits CPU coolers up to 73mm height and supports front cooler up to 280 AIO (max 320mm length radiator).
  • High quality powder coated SGCC steel
  • Tool-less external panels and easy to assemble
  • Rear panel side power switch
  • 6.6ft Up right angle HDMI 2.0 Cable (4K@60Hz) is included in the package.
  • This item requires a extra PCIe riser cable.
🔥Don't forget your OS, we have Windows 11 OEM, Download and USB versions available
Choking Hazard Small parts. Not for children under 3 years.
Overview
Specs
Reviews (13)
avatar

Any questions? Our AI beta will help you find out quickly.

Try me now
Airflow or aesthetics? The choice is yours with Meshroom-S. There's so much mesh that your mouth will water. Breathable, mesh panels let you savor the airflow and minty temps and has a lowkey, vanilla look, like a workstation. Or use the tempered glass side panel that allows your RGB components to shine through with eye-catching brilliance and depth. You'll be like a kid staring inside a candy store. Easy troubleshooting steps to resolve
PCIE 3.0 connection issues: Step
1: Update BIOS on both Motherboard and GPU Update to the newest firmware / BIOS / software for the motherboard and GPU. The newest update can be obtained from the manufacturer's website.
Step 2: Set BIOS to optimal default Overclocking is the main reason for the system to become unstable in Gen 3 setting. Reset BIOS to optimal Gen 3 or 3.0 may resolve the issue and allow the system to run under Gen 3 without issue.
Step 3: Try to boot without the riser cable Make sure the system can boot properly without the riser cable.
Step 4: Clean the connector contacts on the riser cable and GPU Cleaning the connector contact (Gold Fingers) on both GPU and riser cable with rubbing alcohol to remove possible particle build-up.
Step 5: Ensure the cable is fully and securely inserted into the socket Please make sure the male connector (Gold Fingers) is fully inserted into the motherboards PCIe socket. Our riser has a very short pin designed to provide better insertion loss. The pins may not be in full contact with the PCIe socket pins resulting in signal lanes drop from x16 to x8, or worse at x4 speed. Make sure you choose the right length cables. Too long or too short may both result in performance loss.
Step 6: Try a different PCI-e slot (Always choose the PCIe slot closest to the CPU) If the motherboard has multiple Gen 3 PCIe slots, try to install the cable on a different slot.
Step 7: I have done all of the above and Im still having trouble with the riser cable PCI-E specifications do not regulate the use of a riser cable. As a result, Gen 3 motherboards are designed to connect the GPU directly. Hence leave a limited headroom for the use of a riser cable, and the use of a riser cable may fail when the insertion loss is over the limits due to poor components used in motherboards. Not all motherboards and GPUs are manufactured to the same quality, some have higher headroom than the other. In these rare cases, the easiest ways to resolve the problem are: Exchange another riser cable to try. (If shorter length works, always choose a shorter length) Exchange another motherboard of the same brand. Exchange motherboard for a different brand. (99% of the customers have completely resolved the issue at this point) If none of these works, please get in touch with us directly and provide us with your system information (model/make of MB, CPU, GPU, PC case). We are happy to provide a solution.
image for this item
image for this item
Meshroom S

Meshroom S is a highly versatile and compact PC case with only 14.9L volume and full mesh design, which provides excellent ventilation and cooling for even the most demanding components. Despite of its small size, Meshroom S features multiple installation layouts cater to the needs for ATX/MATX motherboard, GPU up to 353mm (with 3cm aluminum feet). For custom loop enthusiasts, the pre-arranged space fulfill the need of dual radiator with a ddc pump.



  • Large GPU support: compatible with 4 slot GPU

  • Fully prepared for configuration of dual radiator plus a ddc pump

  • Versatility build: support ITX/ MATX/ ATX motherboard*

  • Extreme fine mesh panel in 1.5mm aperture on all sides with ultra ventilation

image for this item
About Us

Welcome to Ssupd, where passion meets design. Elevating the builder experience, we forge emotional connections with PC hardware and accessories. Our mission: to make PC building intuitive, enjoyable, and fun. Leading in high-performance PC hardware, our products offer superior cost efficiency. From sleek cases to premium accessories, each component delivers an impactful experience. Empower creativity with quality & affordability for enhanced PC setups.

meshrooms
Breathes Easy, Performs Great

Breathable, mesh panels enables higher airflow and better cooling

meshrooms
Support Up to ATX motherboard

Support Up to ATX motherboard

(extra PCIe card needed for MATX, ATX)

meshrooms
Small footprint, big impact

Minimized footprint with ultimate potential

meshrooms
meshrooms
Easy access for custom loop

Featuring a dual radiator custom loop water-cooling design and assuring with a ddc pump simultaneously

meshrooms
Supply from all power

Choose your power supply size from SFX up to 170mm ATX

meshrooms
Flexible storage

Allow for up to 3 x HDD at the same time

Specifications
Expansion slots Vertical GPU: up to 4 slots; horizontal GPU: 3 slots
PCIe standard PCIe Gen 4.0 x 16
Front IO ports 1 x USB 3.1 Gen 2 Type-C, 2 x USB 3.0
Rear IO ports Power button
Top and front panel Fine mesh panels
Side panel Fine mesh panels
Tool-less push-to-lock Both side, top, and front panels
2.5" drive max mounts Vertical GPU: 3 x SSD; horizontal GPU: 6 x SSD
3.5" drive max mounts Vertical GPU: 1 x HDD; horizontal SFF GPU: 3 x HDD
Front fan mounts 2 x 120/140 mm
Top fan mounts 1 x 120 mm x 15 mm thick
Right side fan mounts 2 x 120/140 mm with 2.5 slot GPU in 4 slots GPU mode
Compatibility
Motherboard compatibility Mini-ITX; Mini-DTX, MATX, ATX (extra PCIe card needed)
Power supply type SFX, SFX-L, ATX
Power supply max length 170 mm ATX PSU with front fan; 150 mm ATX PSU with downward tubing AIO
CPU cooler max height 3 slots GPU mode : max 74 mm height 4 slots GPU mode : max 54 mm height
GPU max length in ITX build Vertical rear: 332mm length, 152mm wide, 82mm thick Horizontal: 212mm length, 160mm wide, 61mm thick
GPU max length in ATX build Front GPU: 314mm length, 120mm wide, 61mm thick Rear GPU: 332mm length, 152mm wide, 62mm thick
Front radiator in ITX build 240/280 mm (max 332 mm length, 144 mm wide, 63 mm thick with fans)
Right side radiator in ITX build 4 slots GPU mode: 45 mm thick of 240/280 mm radiator + fans allow GPU in 32 mm thick
Right side radiator in ATX/MATX build 3 slots GPU mode: 240 mm support max 120 mm wide, 53 mm thick with fans
General
Case dimensions (L x W x H) 247 x 167 x 362 mm / 9.72 x 6.57 x 14.25 inch
Package dimensions (L x W x H) 415 x 220 x 310 mm / 16.34 x 8.66 x 12.2 inch
Net weight 2.95 kg / 6.5 lb
Gross weight 3.5 kg / 7.72 lb
Volume 14.93 liters
Case material SGCC powder coated steel, plastic
Package contents Case, accessory box, user manual
