Brand | SUPERMICRO |
---|---|
Model | AOC-SAS2LP-MV8 |
Type | SATA / SAS |
---|---|
Internal Connectors | 2 x SFF-8087 mini-SAS |
Interface | PCI-Express 2.0 x8 |
Transfer Rate | Up to 6Gb/s |
RAID | JBOD mode only |
Operating Systems Supported | Windows 2003, 2008 and Vista RedHat Enterprise Linux Fedora Linux 9 SuSE Linux Enterprise CentOS |
Dimensions | 6.6" (length) x 2.7" (width) |
Features | Device Support: Up to 8 SAS/SATA disk drives, activity LED indicated for each drive (LED cables not included) Key Application: Storage arrays for Network Attached Storage (NAS) and Nearline Backup 8-channel SAS/SATA adapter with 600MB/s per channel Supermicro's SAS2LP-MV8 controller (based on the Marvell 9480 host controller) provides 8-port SAS/SATA HDD support via PCI-E by 8 bus interface with high-performance features. Serving as a 3rd generation SAS/SATA storage card, the AOC-SAS2LP-MV8 offers double the data transfer rate of its 1st generation counterpart and offers functionalities for server, workstation and network storage environments in a low-profile PCI platform. The SAS2LP-MV8 is ideal for storage arrays for Network Attached Storage (NAS) and Nearline Backup. Built with superior quality and features, the SAS2LP-MV8 will become an integral part of today's data storage solutions. The SAS2LP-MV8 Installation CD contains drivers for Microsoft Windows and RedHat/SuSE/Fedora Linux operating systems. |
---|
Date First Available | September 12, 2013 |
---|
