SUPERMICRO MBD-X12SPM-TF ATX Server Motherboard Socket P+ Intel C621A
- 3rd Gen Intel Xeon Scalable processors, Single Socket LGA-4189 (Socket P+) supported, CPU TDP supports Up to 270W TDP
- Intel C621A
- Up to 2TB 3DS ECC RDIMM, DDR4-3200MHz; Up to 2TB 3DS ECC LRDIMM, DDR4-3200MHz
- Up to 2TB Intel Optane Persistent Memory, in 8 DIMM slots
- 2 PCI-E 4.0 x8, 1 PCI-E 4.0 x16, 1 PCI-E 4.0 x8 (in x16 slot), 3 PCI-E 3.0 x8
- M.2 Interface: 1 SATA/PCI-E 3.0 x4
- M.2 Form Factor: 2280/22110
- M.2 Key: M-Key
- Dual LAN with Intel i210 Gigabit Ethernet Controller
- Intel C621A controller for 10 SATA3 (6 Gbps) ports; RAID 0,1,5,10
+
+
Learn more about the Supermicro MBD-X12SPM-TF
| Brand | SUPERMICRO |
|---|---|
| Model | MBD-X12SPM-TF |
| CPU Socket Type | Socket P+ |
|---|---|
| CPU Type | Supports 3rd Gen Intel Xeon Scalable processors |
| North Bridge | Intel C621A |
|---|
| Number of DDR4 Slots | 8 x 288-pin |
|---|---|
| DDR4 Standard | DDR4 3200 |
| Maximum Memory Supported | Up to 2TB 3DS ECC RDIMM, DDR4-3200MHz; Up to 2TB 3DS ECC LRDIMM, DDR4-3200MHz Up to 2TB Intel Optane Persistent Memory, in 8 DIMM slots |
| ECC Supported | Yes |
| PCI Express 4.0 x16 | 1 |
|---|---|
| PCI Express x8 | 2 x PCI Express 4.0 x8 1 x PCI Express 4.0 x8 (in x16 slot) 3 x PCI Express 3.0 x8 |
| SATA | 10 x SATA 6.0Gb/s |
|---|---|
| SATA RAID | 0/1/5/10 |
| M.2 | M.2 Interface: 1 SATA/PCI-E 3.0 x4 Form Factor: 2280/22110 Key: M-Key |
| Onboard Video Chipset | Aspeed AST2600 |
|---|
| LAN Chipset | Intel I210 |
|---|---|
| LAN Speed | 10/100/1000Mbps |
| Back I/O Ports | 2 x RJ45 Gigabit Ethernet LAN ports 6 x USB 2.0 ports (2 rear + 4 via headers) 5 x USB 3.2 Gen1 ports (2 rear + 2 via headers + 1 Type A) 1 x VGA port 1 x COM Port (1 header) TPM Header |
|---|
| Form Factor | ATX |
|---|---|
| Dimensions (W x L) | 12.1" x 10" |
| First Listed on Newegg | February 18, 2026 |
|---|
Warranty & Returns
Warranty, Returns, And Additional Information
Warranty
- Limited Warranty period (parts): 1 year
- Limited Warranty period (labor): 3 years
- Read full details
Return Policies
- Return for refund until: January 31, 2027
- Return for replacement until: January 31, 2027
- This item is covered by Newegg.com's Extended Holiday Return Policy.
- Read full return policy for details.
We want to ensure your holiday shopping this year is hassle-free. That’s why we’re automatically extending our return policies on almost every product! For purchases placed between November 1st, 2026 and December 31, 2026 you will have until January 31, 2027 to return your product.
Manufacturer Contact Info
- Manufacturer Product Page
- Manufacturer Website
- Support Phone: 1-408-503-8000
- Support Website
- View other products from Supermicro
LOADING...
The SUPERMICRO MBD-X12SPM-TF is an ATX server motherboard for 3rd Gen Intel Xeon Scalable processors, suited to server builds that need ECC memory, extensive PCIe expansion, and up to 10 SATA drives.
Recommended For
- Homelab builders running Proxmox or similar virtualization who want a single-socket Xeon platform with ECC memory and remote server management; community posts describe X12SPM-TF systems used for Proxmox servers.
- Small-server builders who need dual 10GbE networking and out-of-band management for administering a machine remotely, rather than relying on it as a consumer desktop.
- Storage-server builders who plan to connect multiple SATA drives and add storage or networking cards, using the board’s SATA ports, PCIe slots, and NVMe-capable SlimSAS connectors.
- Compute or virtualization users who specifically need a server platform for registered ECC memory and large memory capacity, and are prepared to choose a compatible third-generation Xeon Scalable processor and memory.
Spec Summary
| Attribute | Value |
|---|---|
| Best For | Server builds using a 3rd Gen Intel Xeon Scalable processor, ECC DDR4 memory, and multiple PCIe expansion cards |
| Processor And Platform | Supports 3rd Gen Intel Xeon Scalable processors on Socket P+ with the Intel C621A chipset |
| Memory Configuration | Eight 288-pin DDR4-3200 slots support up to 2TB of 3DS ECC RDIMM or LRDIMM memory, plus up to 2TB of Intel Optane Persistent Memory |
| PCIe Expansion | Includes one PCIe 4.0 x16 slot, two PCIe 4.0 x8 slots, one PCIe 4.0 x8 connection in an x16 slot, and three PCIe 3.0 x8 slots |
| Storage And RAID | Ten SATA 6Gb/s ports support RAID 0, 1, 5, and 10 |
| M.2 Storage | One M.2 M-Key slot supports SATA or PCIe 3.0 x4 drives in 2280 or 22110 form factors |
| Networking | Intel I210 Gigabit Ethernet with two RJ45 LAN ports supporting 10/100/1000Mbps |
| Onboard Graphics | Aspeed AST2600 onboard video chipset |
| I/O And Headers | Rear I/O includes six USB 2.0 ports, two USB 3.2 Gen1 ports, two Gigabit Ethernet ports, and VGA; headers provide four USB 2.0 ports, two USB 3.2 Gen1 ports, one COM port, and TPM connectivity, with one additional USB Type-A port |
| Board Format And Dimensions | ATX motherboard measuring 12.1 × 10 inches |
| Model Identifiers | SUPERMICRO MBD-X12SPM-TF |
