SUPERMICRO P8SCT ATX Server Motherboard LGA 775 Intel E7221
- LGA 775
- Intel E7221
- 4 x 240Pin
Specs
Reviews (1)
Any questions? Our AI beta will help you find out quickly.
Try me now
Learn more about the Supermicro P8SCT
| Brand | SUPERMICRO |
|---|---|
| Model | P8SCT |
| CPU Socket Type | LGA 775 |
|---|---|
| CPU Type | Intel Pentium 4 (Prescott Ready) / Celeron |
| System Bus | 800/533 MHz |
| Supported CPU Technologies | Hyper-Threading Technology |
| North Bridge | Intel E7221 |
|---|---|
| South Bridge | Intel ICH6R |
| Number of DDR2 Slots | 4 x 240Pin |
|---|---|
| Maximum Memory Supported | 4GB |
| Channel Supported | Dual Channel |
| ECC Supported | Yes |
| PCI-X Slots (64-bit 133MHz) | 1 |
|---|---|
| PCI Slots | 5 x PCI Slots |
| PATA | 1 x ATA 100 2 Dev. Max |
|---|---|
| SATA | 4 x SATA 1.5Gb/s |
| SATA RAID | 0/1 |
| Onboard Video Chipset | Integrated 2D and 3D Graphics |
|---|
| LAN Chipset | Broadcom BCM5721 |
|---|---|
| LAN Speed | 10/100/1000Mbps |
| Second LAN Chipset | Broadcom BCM5721 |
| Second LAN Speed | 10/100/1000Mbps |
| Max LAN Speed | 1Gbps |
| PS/2 | 2 |
|---|---|
| COM | 1 |
| LPT | 1 |
| Video Ports | 1 |
| USB 1.1/2.0 | 4 x USB 2.0 |
| Features | 1. Intel® Pentium® 4 LGA775 Package 800MHz FSB, Celeron® 533MHz FSB 2. Intel® E7221 (Copper River) Chipset & integrated server-quality onboard video 3. Up to 4GB DDRII 400/533MHz unbuffered ECC/non-ECC SDRAM 4. Dual Broadcom BCM5721 Gigabit LAN Controllers 5. Built-in SATA Controller 4x SATA Drive Support 6. 1x 64-bit 133MHz PCI-X 5x 32-bit 33MHz PCI 7. Support for IPMI 2.0 |
|---|
| Form Factor | ATX |
|---|---|
| Dimensions (W x L) | 12" x 9.5 ", (30.5cm x 24.2cm |
| First Listed on Newegg | June 09, 2005 |
|---|
